WRE-0400-RD (PK-100)
External Retaining Rings - 40x2.5x37.5 mm Round Wire - Carbon Spring Steel Circlip
MBA
Store: Minibearings - Miniature Bearings Australia - Domestic & ExportAnderton and Seeger Cross Reference PDF
Circlips PDF Catalogue
Order 50 or more packs of 100 (5000 pcs)
for $79.97 AUD per 100 pack
40x2.5x37.5 mm External Retaining Rings - Carbon Spring Steel - Sold per pack of 100:
Base Category: Retaining Rings - External
Top Level Category: Retaining Rings - External - Round Wire
Product Details
Shaft Diameter (Ds): 40.00mm(40.00mm is 1.575 in.)
Carbon Spring Steel
- Shaft Diameter (Ds): 40.00mm
(40.00mm is 1.575 in.)
- Clip Thickness (T): 2.50mm
(2.50mm is 0.098 in.)
- Groove Dia. (Dg): 37.5mm
+ 0 / - 0.60
(37.5mm is 1.476 in.)
- Approx. Loose Circlip ID (A): 37.1mm
- Radial Wall (S) Approx.: 37.5mm
+/- 0.10
- Groove Width (W): 2.8mm
Min.
- Free Outside Dia (Dr): 42.1
- Section Profile: Round Section
Brand: MBA
Country of Origin: US
Product Compliance and Data
Similar to
- Huyett® DRP-040
- NoCor® DRP-040
- DRP040
We offer equivalents to many brands including Anderton, Barden, Berg, Designatronics, EZO, ISC, Koyo, Myonic, NMB, Nordex, NSK, Ondrives, Reid Industrial, RMB, SDP-SI, Seeger, SKF, and more.
WRE0400RD, WRE0400
