DAK-025 (5 Pcs)

External Retaining Rings - 25x1.2x23.9 mm - Carbon Steel

Images are indicative only and may not represent the pack quantity or specific item details. Images should be used as a guide in conjunction with the product description.
  • External Retaining Rings - 25x1.2x23.9 mm - Carbon Steel
1 4

MBA

Store Name: Miniature Bearings Australia (Minibearings)

Additional resources:
Anderton and Seeger Cross Reference PDF
Circlips PDF Catalogue
Assortment Kits
Price:
$12.50 AUD
$12.50 AUD
per 5
Qty: 9 packs (45 pcs) available now
Order 50 or more packs (250 pcs) for $11.25 AUD per 5
You may order more than the quantity available. One delivery will be made when all items are ready unless you select for partial delivery at checkout. Backorders for more than the stock quantity are expected before Jul 22, 2025

Base Category: Retaining Rings - External

Top Level Category: Retaining Rings - External - Circlips - Tabbed

Product Details:

Additional stock available from USA subject to Prior Sale = 9


Shaft Diameter (Ds): 25.00mm
(25.00mm is 0.984 in.)

Carbon Steel
  • Clip Thickness (T): 1.20mm
    + 0.00 / - 0.21
    (1.20mm is 0.047 in.)
  • Groove Dia. (Dg): 23.90mm
    + 0.00 / - 0.06
    (23.90mm is 0.941 in.)
  • Approx. Loose Circlip ID (A): 22.78mm
  • Groove Width (W): 1.30mm
  • Tool: PRS-E018

Brand: MBA
Country of Origin: US

Alternative Parts Include: AK25X1.2, AK25-BLS, AK25BLS, DAK-025, DAK025, Seeger, Smalley

We offer equivalents to many brands including Anderton, Barden, Berg, Designatronics, EZO, ISC, Koyo, Myonic, NMB, Nordex, NSK, Ondrives, Reid Industrial, RMB, SDP-SI, Seeger, SKF, and more.
