Collection: Housing Assembly - Offset
Housing Assembly -> OffsetThere are 27 products in the sub-categories of Housing Assembly - Offset. Scroll down or follow the link to Housing Assembly - Offset in the products table to see all these items combined into a handy table with filters. To narrow down the selection, please choose a sub-category from the links below.

Housing Assembly - Offset - Thermoplastic and Chrome Steel
A selection of Thermoplastic and Chrome Steel Offset Housing Assembly. Thermoplastic housed...

Housing Assembly - Offset - Thermoplastic and Stainless
A selection of Thermoplastic and Stainless Offset Housing Assembly. Thermoplastic housed units...
Category Details
This category includes various types of offset housing assembly.
- An expanded range may be available on special order. Please enquire.
Miniature Bearings Australia - MBA Minibearings
Additional resources:
A more concise listing may be found in the Housing Assembly - Offset category on the Small Parts & Bearings online store.
Inside Diameter | Centre Height (A) | Length (B) | Width (C) | Foot Height (D) | Bolt Centres (E) |
Indicative Image |
---|---|---|---|---|---|---|
Inside Diameter
12.700
mm (Equiv. 0.5 in.) |
Centre Height (A)
63.500
mm (Equiv. 2.5 in.) |
Length (B)
61.900
mm (Equiv. 2.437 in.) |
Width (C)
38.100
mm |
Foot Height (D)
11.100
mm |
Bolt Centres (E)
33.325
mm |
![]() |
Bolt Hole Size (G): 9.922 mm
Height (H): 12.700 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-196RS
Offset Housing Assembly - 12.7x63.5x61.9 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$320.41 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter | Centre Height (A) | Length (B) | Width (C) |
Indicative Image |
||
Inside Diameter
12.700
mm (Equiv. 0.5 in.) |
Centre Height (A)
63.500
mm (Equiv. 2.5 in.) |
Length (B)
61.900
mm (Equiv. 2.437 in.) |
Width (C)
38.100
mm |
![]() |
||
Foot Height (D): 11.100 mm
Bolt Centres (E): 33.325 mm
Bolt Hole Size (G): 9.922 mm
Height (H): 12.700 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-196RS
Offset Housing Assembly - 12.7x63.5x61.9 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$320.41 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
15.875
mm (Equiv. 0.625 in.) |
Centre Height (A)
63.500
mm (Equiv. 2.5 in.) |
Length (B)
61.900
mm (Equiv. 2.437 in.) |
Width (C)
38.100
mm |
Foot Height (D)
11.100
mm |
Bolt Centres (E)
33.325
mm |
![]() |
Bolt Hole Size (G): 9.922 mm
Height (H): 12.700 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-197RS
Offset Housing Assembly - 15.875x63.5x61.9 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$294.95 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
15.875
mm (Equiv. 0.625 in.) |
Centre Height (A)
63.500
mm (Equiv. 2.5 in.) |
Length (B)
61.900
mm (Equiv. 2.437 in.) |
Width (C)
38.100
mm |
![]() |
||
Foot Height (D): 11.100 mm
Bolt Centres (E): 33.325 mm
Bolt Hole Size (G): 9.922 mm
Height (H): 12.700 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-197RS
Offset Housing Assembly - 15.875x63.5x61.9 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$294.95 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
19.050
mm (Equiv. 0.75 in.) |
Centre Height (A)
63.500
mm (Equiv. 2.5 in.) |
Length (B)
61.900
mm (Equiv. 2.437 in.) |
Width (C)
38.100
mm |
Foot Height (D)
11.100
mm |
Bolt Centres (E)
33.325
mm |
![]() |
Bolt Hole Size (G): 9.922 mm
Height (H): 12.700 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-272RS
Offset Housing Assembly - 19.05x63.5x61.9 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$227.77 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
19.050
mm (Equiv. 0.75 in.) |
Centre Height (A)
63.500
mm (Equiv. 2.5 in.) |
Length (B)
61.900
mm (Equiv. 2.437 in.) |
Width (C)
38.100
mm |
![]() |
||
Foot Height (D): 11.100 mm
Bolt Centres (E): 33.325 mm
Bolt Hole Size (G): 9.922 mm
Height (H): 12.700 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-272RS
Offset Housing Assembly - 19.05x63.5x61.9 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$227.77 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
19.050
mm (Equiv. 0.75 in.) |
Centre Height (A)
63.500
mm (Equiv. 2.5 in.) |
Length (B)
61.900
mm (Equiv. 2.437 in.) |
Width (C)
38.100
mm |
Foot Height (D)
11.100
mm |
Bolt Centres (E)
33.325
mm |
![]() |
Bolt Hole Size (G): 9.922 mm
Height (H): 12.700 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-198RS
Offset Housing Assembly - 19.05x63.5x61.9 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$301.95 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
19.050
mm (Equiv. 0.75 in.) |
Centre Height (A)
63.500
mm (Equiv. 2.5 in.) |
Length (B)
61.900
mm (Equiv. 2.437 in.) |
Width (C)
38.100
mm |
![]() |
||
Foot Height (D): 11.100 mm
Bolt Centres (E): 33.325 mm
Bolt Hole Size (G): 9.922 mm
Height (H): 12.700 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-198RS
Offset Housing Assembly - 19.05x63.5x61.9 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$301.95 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
20.000
mm (Equiv. 0.787 in.) |
Centre Height (A)
64.000
mm (Equiv. 2.52 in.) |
Length (B)
62.000
mm (Equiv. 2.441 in.) |
Width (C)
38.100
mm |
Foot Height (D)
11.000
mm |
Bolt Centres (E)
33.300
mm |
![]() |
Bolt Hole Size (G): 9.900 mm
Height (H): 12.700 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-199RS
Offset Housing Assembly - 20x64x62 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$304.86 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
20.000
mm (Equiv. 0.787 in.) |
Centre Height (A)
64.000
mm (Equiv. 2.52 in.) |
Length (B)
62.000
mm (Equiv. 2.441 in.) |
Width (C)
38.100
mm |
![]() |
||
Foot Height (D): 11.000 mm
Bolt Centres (E): 33.300 mm
Bolt Hole Size (G): 9.900 mm
Height (H): 12.700 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-199RS
Offset Housing Assembly - 20x64x62 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$304.86 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
20.000
mm (Equiv. 0.787 in.) |
Centre Height (A)
64.000
mm (Equiv. 2.52 in.) |
Length (B)
62.000
mm (Equiv. 2.441 in.) |
Width (C)
38.100
mm |
Foot Height (D)
11.000
mm |
Bolt Centres (E)
33.300
mm |
![]() |
Bolt Hole Size (G): 9.900 mm
Height (H): 12.700 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-273RS
Offset Housing Assembly - 20x64x62 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$200.32 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
20.000
mm (Equiv. 0.787 in.) |
Centre Height (A)
64.000
mm (Equiv. 2.52 in.) |
Length (B)
62.000
mm (Equiv. 2.441 in.) |
Width (C)
38.100
mm |
![]() |
||
Foot Height (D): 11.000 mm
Bolt Centres (E): 33.300 mm
Bolt Hole Size (G): 9.900 mm
Height (H): 12.700 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-273RS
Offset Housing Assembly - 20x64x62 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$200.32 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
22.225
mm (Equiv. 0.875 in.) |
Centre Height (A)
69.850
mm (Equiv. 2.75 in.) |
Length (B)
63.500
mm (Equiv. 2.5 in.) |
Width (C)
41.275
mm |
Foot Height (D)
11.100
mm |
Bolt Centres (E)
37.306
mm |
![]() |
Bolt Hole Size (G): 9.922 mm
Height (H): 14.300 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-200RS
Offset Housing Assembly - 22.225x69.85x63.5 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$309.86 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
22.225
mm (Equiv. 0.875 in.) |
Centre Height (A)
69.850
mm (Equiv. 2.75 in.) |
Length (B)
63.500
mm (Equiv. 2.5 in.) |
Width (C)
41.275
mm |
![]() |
||
Foot Height (D): 11.100 mm
Bolt Centres (E): 37.306 mm
Bolt Hole Size (G): 9.922 mm
Height (H): 14.300 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-200RS
Offset Housing Assembly - 22.225x69.85x63.5 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$309.86 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
25.000
mm (Equiv. 0.984 in.) |
Centre Height (A)
70.000
mm (Equiv. 2.756 in.) |
Length (B)
64.000
mm (Equiv. 2.52 in.) |
Width (C)
41.300
mm |
Foot Height (D)
11.000
mm |
Bolt Centres (E)
37.100
mm |
![]() |
Bolt Hole Size (G): 9.900 mm
Height (H): 14.300 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-275RS
Offset Housing Assembly - 25x70x64 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$220.14 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
25.000
mm (Equiv. 0.984 in.) |
Centre Height (A)
70.000
mm (Equiv. 2.756 in.) |
Length (B)
64.000
mm (Equiv. 2.52 in.) |
Width (C)
41.300
mm |
![]() |
||
Foot Height (D): 11.000 mm
Bolt Centres (E): 37.100 mm
Bolt Hole Size (G): 9.900 mm
Height (H): 14.300 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-275RS
Offset Housing Assembly - 25x70x64 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$220.14 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
25.000
mm (Equiv. 0.984 in.) |
Centre Height (A)
70.000
mm (Equiv. 2.756 in.) |
Length (B)
64.000
mm (Equiv. 2.52 in.) |
Width (C)
41.300
mm |
Foot Height (D)
11.000
mm |
Bolt Centres (E)
37.100
mm |
![]() |
Bolt Hole Size (G): 9.900 mm
Height (H): 14.300 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-201RS
Offset Housing Assembly - 25x70x64 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$335.23 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
25.000
mm (Equiv. 0.984 in.) |
Centre Height (A)
70.000
mm (Equiv. 2.756 in.) |
Length (B)
64.000
mm (Equiv. 2.52 in.) |
Width (C)
41.300
mm |
![]() |
||
Foot Height (D): 11.000 mm
Bolt Centres (E): 37.100 mm
Bolt Hole Size (G): 9.900 mm
Height (H): 14.300 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-201RS
Offset Housing Assembly - 25x70x64 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$335.23 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
25.400
mm (Equiv. 1 in.) |
Centre Height (A)
69.850
mm (Equiv. 2.75 in.) |
Length (B)
63.500
mm (Equiv. 2.5 in.) |
Width (C)
41.275
mm |
Foot Height (D)
11.100
mm |
Bolt Centres (E)
37.306
mm |
![]() |
Bolt Hole Size (G): 9.922 mm
Height (H): 14.300 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-202RS
Offset Housing Assembly - 25.4x69.85x63.5 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$311.68 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
25.400
mm (Equiv. 1 in.) |
Centre Height (A)
69.850
mm (Equiv. 2.75 in.) |
Length (B)
63.500
mm (Equiv. 2.5 in.) |
Width (C)
41.275
mm |
![]() |
||
Foot Height (D): 11.100 mm
Bolt Centres (E): 37.306 mm
Bolt Hole Size (G): 9.922 mm
Height (H): 14.300 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-202RS
Offset Housing Assembly - 25.4x69.85x63.5 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$311.68 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
28.575
mm (Equiv. 1.125 in.) |
Centre Height (A)
82.550
mm (Equiv. 3.25 in.) |
Length (B)
76.200
mm (Equiv. 3 in.) |
Width (C)
47.625
mm |
Foot Height (D)
13.494
mm |
Bolt Centres (E)
40.481
mm |
![]() |
Bolt Hole Size (G): 9.922 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-277RS
Offset Housing Assembly - 28.575x82.55x76.2 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$264.95 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
28.575
mm (Equiv. 1.125 in.) |
Centre Height (A)
82.550
mm (Equiv. 3.25 in.) |
Length (B)
76.200
mm (Equiv. 3 in.) |
Width (C)
47.625
mm |
![]() |
||
Foot Height (D): 13.494 mm
Bolt Centres (E): 40.481 mm
Bolt Hole Size (G): 9.922 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-277RS
Offset Housing Assembly - 28.575x82.55x76.2 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$264.95 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
28.575
mm (Equiv. 1.125 in.) |
Centre Height (A)
82.550
mm (Equiv. 3.25 in.) |
Length (B)
76.200
mm (Equiv. 3 in.) |
Width (C)
47.625
mm |
Foot Height (D)
13.494
mm |
Bolt Centres (E)
40.481
mm |
![]() |
Bolt Hole Size (G): 9.922 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-203RS
Offset Housing Assembly - 28.575x82.55x76.2 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$399.14 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
28.575
mm (Equiv. 1.125 in.) |
Centre Height (A)
82.550
mm (Equiv. 3.25 in.) |
Length (B)
76.200
mm (Equiv. 3 in.) |
Width (C)
47.625
mm |
![]() |
||
Foot Height (D): 13.494 mm
Bolt Centres (E): 40.481 mm
Bolt Hole Size (G): 9.922 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-203RS
Offset Housing Assembly - 28.575x82.55x76.2 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$399.14 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
30.000
mm (Equiv. 1.181 in.) |
Centre Height (A)
83.000
mm (Equiv. 3.268 in.) |
Length (B)
76.000
mm (Equiv. 2.992 in.) |
Width (C)
47.600
mm |
Foot Height (D)
13.000
mm |
Bolt Centres (E)
40.600
mm |
![]() |
Bolt Hole Size (G): 9.900 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-204RS
Offset Housing Assembly - 30x83x76 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$410.14 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
30.000
mm (Equiv. 1.181 in.) |
Centre Height (A)
83.000
mm (Equiv. 3.268 in.) |
Length (B)
76.000
mm (Equiv. 2.992 in.) |
Width (C)
47.600
mm |
![]() |
||
Foot Height (D): 13.000 mm
Bolt Centres (E): 40.600 mm
Bolt Hole Size (G): 9.900 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-204RS
Offset Housing Assembly - 30x83x76 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$410.14 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
30.000
mm (Equiv. 1.181 in.) |
Centre Height (A)
83.000
mm (Equiv. 3.268 in.) |
Length (B)
76.000
mm (Equiv. 2.992 in.) |
Width (C)
47.600
mm |
Foot Height (D)
13.000
mm |
Bolt Centres (E)
40.600
mm |
![]() |
Bolt Hole Size (G): 9.900 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-278RS
Offset Housing Assembly - 30x83x76 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$263.86 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
30.000
mm (Equiv. 1.181 in.) |
Centre Height (A)
83.000
mm (Equiv. 3.268 in.) |
Length (B)
76.000
mm (Equiv. 2.992 in.) |
Width (C)
47.600
mm |
![]() |
||
Foot Height (D): 13.000 mm
Bolt Centres (E): 40.600 mm
Bolt Hole Size (G): 9.900 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-278RS
Offset Housing Assembly - 30x83x76 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$263.86 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
30.163
mm (Equiv. 1.188 in.) |
Centre Height (A)
82.550
mm (Equiv. 3.25 in.) |
Length (B)
76.200
mm (Equiv. 3 in.) |
Width (C)
47.625
mm |
Foot Height (D)
13.494
mm |
Bolt Centres (E)
40.481
mm |
![]() |
Bolt Hole Size (G): 9.922 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-205RS
Offset Housing Assembly - 30.163x82.55x76.2 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$408.32 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
30.163
mm (Equiv. 1.188 in.) |
Centre Height (A)
82.550
mm (Equiv. 3.25 in.) |
Length (B)
76.200
mm (Equiv. 3 in.) |
Width (C)
47.625
mm |
![]() |
||
Foot Height (D): 13.494 mm
Bolt Centres (E): 40.481 mm
Bolt Hole Size (G): 9.922 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-205RS
Offset Housing Assembly - 30.163x82.55x76.2 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$408.32 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
30.163
mm (Equiv. 1.188 in.) |
Centre Height (A)
82.550
mm (Equiv. 3.25 in.) |
Length (B)
76.200
mm (Equiv. 3 in.) |
Width (C)
47.625
mm |
Foot Height (D)
13.494
mm |
Bolt Centres (E)
40.481
mm |
![]() |
Bolt Hole Size (G): 9.922 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-279RS
Offset Housing Assembly - 30.163x82.55x76.2 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$264.95 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
30.163
mm (Equiv. 1.188 in.) |
Centre Height (A)
82.550
mm (Equiv. 3.25 in.) |
Length (B)
76.200
mm (Equiv. 3 in.) |
Width (C)
47.625
mm |
![]() |
||
Foot Height (D): 13.494 mm
Bolt Centres (E): 40.481 mm
Bolt Hole Size (G): 9.922 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-279RS
Offset Housing Assembly - 30.163x82.55x76.2 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$264.95 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
31.75 S
mm (Equiv. 1.25 in.) |
Centre Height (A)
82.550
mm (Equiv. 3.25 in.) |
Length (B)
76.200
mm (Equiv. 3 in.) |
Width (C)
47.625
mm |
Foot Height (D)
13.494
mm |
Bolt Centres (E)
40.481
mm |
![]() |
Bolt Hole Size (G): 9.922 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-280RS
Offset Housing Assembly - 31.75 S 82.55x76.2 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$248.41 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
31.75 S
mm (Equiv. 1.25 in.) |
Centre Height (A)
82.550
mm (Equiv. 3.25 in.) |
Length (B)
76.200
mm (Equiv. 3 in.) |
Width (C)
47.625
mm |
![]() |
||
Foot Height (D): 13.494 mm
Bolt Centres (E): 40.481 mm
Bolt Hole Size (G): 9.922 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-280RS
Offset Housing Assembly - 31.75 S 82.55x76.2 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$248.41 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
31.75 S
mm (Equiv. 1.25 in.) |
Centre Height (A)
82.550
mm (Equiv. 3.25 in.) |
Length (B)
76.200
mm (Equiv. 3 in.) |
Width (C)
47.625
mm |
Foot Height (D)
13.494
mm |
Bolt Centres (E)
40.481
mm |
![]() |
Bolt Hole Size (G): 9.922 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-206RS
Offset Housing Assembly - 31.75 S 82.55x76.2 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$399.14 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
31.75 S
mm (Equiv. 1.25 in.) |
Centre Height (A)
82.550
mm (Equiv. 3.25 in.) |
Length (B)
76.200
mm (Equiv. 3 in.) |
Width (C)
47.625
mm |
![]() |
||
Foot Height (D): 13.494 mm
Bolt Centres (E): 40.481 mm
Bolt Hole Size (G): 9.922 mm
Height (H): 15.900 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-206RS
Offset Housing Assembly - 31.75 S 82.55x76.2 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$399.14 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
31.750
mm (Equiv. 1.25 in.) |
Centre Height (A)
95.250
mm (Equiv. 3.75 in.) |
Length (B)
88.900
mm (Equiv. 3.5 in.) |
Width (C)
50.800
mm |
Foot Height (D)
16.272
mm |
Bolt Centres (E)
44.847
mm |
![]() |
Bolt Hole Size (G): 13.097 mm
Height (H): 17.501 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-207RS
Offset Housing Assembly - 31.75x95.25x88.9 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$476.32 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
31.750
mm (Equiv. 1.25 in.) |
Centre Height (A)
95.250
mm (Equiv. 3.75 in.) |
Length (B)
88.900
mm (Equiv. 3.5 in.) |
Width (C)
50.800
mm |
![]() |
||
Foot Height (D): 16.272 mm
Bolt Centres (E): 44.847 mm
Bolt Hole Size (G): 13.097 mm
Height (H): 17.501 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-207RS
Offset Housing Assembly - 31.75x95.25x88.9 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$476.32 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
31.750
mm (Equiv. 1.25 in.) |
Centre Height (A)
95.250
mm (Equiv. 3.75 in.) |
Length (B)
88.900
mm (Equiv. 3.5 in.) |
Width (C)
50.800
mm |
Foot Height (D)
16.272
mm |
Bolt Centres (E)
44.847
mm |
![]() |
Bolt Hole Size (G): 13.097 mm
Height (H): 17.501 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-281RS
Offset Housing Assembly - 31.75x95.25x88.9 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$303.50 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
31.750
mm (Equiv. 1.25 in.) |
Centre Height (A)
95.250
mm (Equiv. 3.75 in.) |
Length (B)
88.900
mm (Equiv. 3.5 in.) |
Width (C)
50.800
mm |
![]() |
||
Foot Height (D): 16.272 mm
Bolt Centres (E): 44.847 mm
Bolt Hole Size (G): 13.097 mm
Height (H): 17.501 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-281RS
Offset Housing Assembly - 31.75x95.25x88.9 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$303.50 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
33.338
mm (Equiv. 1.313 in.) |
Centre Height (A)
95.250
mm (Equiv. 3.75 in.) |
Length (B)
88.900
mm (Equiv. 3.5 in.) |
Width (C)
50.800
mm |
Foot Height (D)
16.272
mm |
Bolt Centres (E)
44.847
mm |
![]() |
Bolt Hole Size (G): 13.097 mm
Height (H): 17.501 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-208RS
Offset Housing Assembly - 33.338x95.25x88.9 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$490.68 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
33.338
mm (Equiv. 1.313 in.) |
Centre Height (A)
95.250
mm (Equiv. 3.75 in.) |
Length (B)
88.900
mm (Equiv. 3.5 in.) |
Width (C)
50.800
mm |
![]() |
||
Foot Height (D): 16.272 mm
Bolt Centres (E): 44.847 mm
Bolt Hole Size (G): 13.097 mm
Height (H): 17.501 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-208RS
Offset Housing Assembly - 33.338x95.25x88.9 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$490.68 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
34.925
mm (Equiv. 1.375 in.) |
Centre Height (A)
95.250
mm (Equiv. 3.75 in.) |
Length (B)
88.900
mm (Equiv. 3.5 in.) |
Width (C)
50.800
mm |
Foot Height (D)
16.272
mm |
Bolt Centres (E)
44.847
mm |
![]() |
Bolt Hole Size (G): 13.097 mm
Height (H): 17.501 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-282RS
Offset Housing Assembly - 34.925x95.25x88.9 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$303.50 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
34.925
mm (Equiv. 1.375 in.) |
Centre Height (A)
95.250
mm (Equiv. 3.75 in.) |
Length (B)
88.900
mm (Equiv. 3.5 in.) |
Width (C)
50.800
mm |
![]() |
||
Foot Height (D): 16.272 mm
Bolt Centres (E): 44.847 mm
Bolt Hole Size (G): 13.097 mm
Height (H): 17.501 mm
Category: Housing Assembly - Offset - Thermoplastic and Chrome Steel |
||||||
Part Number: IP-282RS
Offset Housing Assembly - 34.925x95.25x88.9 mm Thermoplastic and Chrome Steel Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$303.50 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
34.925
mm (Equiv. 1.375 in.) |
Centre Height (A)
95.250
mm (Equiv. 3.75 in.) |
Length (B)
88.900
mm (Equiv. 3.5 in.) |
Width (C)
50.800
mm |
Foot Height (D)
16.272
mm |
Bolt Centres (E)
44.847
mm |
![]() |
Bolt Hole Size (G): 13.097 mm
Height (H): 17.501 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-209RS
Offset Housing Assembly - 34.925x95.25x88.9 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$476.32 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
34.925
mm (Equiv. 1.375 in.) |
Centre Height (A)
95.250
mm (Equiv. 3.75 in.) |
Length (B)
88.900
mm (Equiv. 3.5 in.) |
Width (C)
50.800
mm |
![]() |
||
Foot Height (D): 16.272 mm
Bolt Centres (E): 44.847 mm
Bolt Hole Size (G): 13.097 mm
Height (H): 17.501 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-209RS
Offset Housing Assembly - 34.925x95.25x88.9 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$476.32 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
||||||
Inside Diameter
35.000
mm (Equiv. 1.378 in.) |
Centre Height (A)
95.000
mm (Equiv. 3.74 in.) |
Length (B)
89.000
mm (Equiv. 3.504 in.) |
Width (C)
50.800
mm |
Foot Height (D)
16.000
mm |
Bolt Centres (E)
45.000
mm |
![]() |
Bolt Hole Size (G): 13.100 mm
Height (H): 17.500 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-210RS
Offset Housing Assembly - 35x95x89 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$490.68 AUD
Regular price
Unit price
/
per
Each
|
||||||
Inside Diameter
35.000
mm (Equiv. 1.378 in.) |
Centre Height (A)
95.000
mm (Equiv. 3.74 in.) |
Length (B)
89.000
mm (Equiv. 3.504 in.) |
Width (C)
50.800
mm |
![]() |
||
Foot Height (D): 16.000 mm
Bolt Centres (E): 45.000 mm
Bolt Hole Size (G): 13.100 mm
Height (H): 17.500 mm
Category: Housing Assembly - Offset - Thermoplastic and Stainless |
||||||
Part Number: IP-210RS
Offset Housing Assembly - 35x95x89 mm Thermoplastic and Stainless Out of Stock | Backorder Now | Orders can be expected around Mon, Sep 01, 2025 Regular price
$490.68 AUD
Regular price
Unit price
/
per
Each
|
||||||
|
