S691-MC3-JP6

Single Row Ball Bearings - 1x4x1.6 mm Unflanged - Stainless Steel AISI 440C Bearing

Images are indicative only and may not represent the pack quantity or specific item details. Images should be used as a guide in conjunction with the product description.
NaN -Infinity

MBA

Store: Minibearings - Miniature Bearings Australia - Domestic & Export Additional resources:
Tolerances
Standard Bearings PDF Catalogue
Shafting
Price:
$5.29 AUD
$6.35 AUD $5.29 AUD
Each
Qty: 10 available now
Only 10 may be ordered online. If you need a large quantity, please contact us.

Couldn't load pickup availability

Base Category: Bearings - Single Row Ball

Top Level Category: Bearings - Single Row Ball - Unflanged - Precision - 440C Stainless

Product Details

ID (d): 1.000mm
+ 0.000 / - 0.007
(1.000mm is 0.039 in.)

Stainless Steel AISI 440C
  • OD (D): 4.000mm
    + 0.000 / - 0.007
    (4.000mm is 0.157 in.)
  • Width (B): 1.600mm
    + 0.000 / - 0.040
    (1.600mm is 0.063 in.)
  • Precision Grade: P6
  • Closure Type: Open
  • Bearing Type: Radial

Brand: MBA
Country of Origin: JP

Product Compliance and Data

Similar to

  • ISO 691HP6
  • ISO 691H-P6
  • GRW 691-P6
  • GRW S691-P6
  • MPB SEL1C
  • SS-R410
  • SSR410
  • DDR410
  • DD-R410
  • 691P6
  • S691P6
  • 691BASIC

We offer equivalents to many brands including Anderton, Barden, Berg, Designatronics, EZO, ISC, Koyo, Myonic, NMB, Nordex, NSK, Ondrives, Reid Industrial, RMB, SDP-SI, Seeger, SKF, and more.
