Collection: Pulleys - Metric Timing - 5.000mm Pitch - T5 - 10mm Wide

Pulleys (With Images)

Metric Timing

5.000mm Pitch

10mm Wide
16mm Wide
25mm Wide

20 Products in this selection

Timing Pulleys to suit T Series 5.000mm Pitch Timing Belts. Suits belts 9.5 to 10.0mm wide.
Aluminium alloy
No locking provided. You will need to drill and tap the hub to suit your desired grub screw.
Tapped hubs can be provided on request

Additional resources:
Timing Pulleys Catalogue PDF
T 5mm Timing Belts

A more concise listing may be found on the Smallparts store at Pulleys - Metric Timing - 5.000mm Pitch - T5 - 10mm Wide. Smallparts promote the most popular MBA products.

Teeth	Max Belt Width	Bore (d)	Bore Type	Locking Type
Teeth 10	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 4.000 mm _{(0.157 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 15.91 mm Flange Diameter (FD): 20.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 8.0
Part Number: P-050T-010-100FF-AS-N-040 Metric Timing Pulleys - 10 tooth - 10x4 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $35.32 AUD Regular price ~~$42.38 AUD~~ Sale price $35.32 AUD Unit price per Each
Teeth	Max Belt Width	Bore (d)	Bore Type	Indicative Image
Teeth 10	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 4.000 mm _{(0.157 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 15.91 mm Flange Diameter (FD): 20.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 8.0
Part Number: P-050T-010-100FF-AS-N-040 Metric Timing Pulleys - 10 tooth - 10x4 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $35.32 AUD Regular price ~~$42.38 AUD~~ Sale price $35.32 AUD Unit price per Each View the product page first if you are unsure.
P-050T-010-100FF-AS-N-040 --- Metric Timing Pulleys - 10 tooth - 10x4 mm - Aluminium with Steel Flanges Sale P-050T-010-100FF-AS-N-040 --- Metric Timing Pulleys - 10 tooth - 10x4 mm - Aluminium with Steel Flanges Regular price $35.32 AUD Regular price ~~$42.38 AUD~~ Sale price $35.32 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 12	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 4.000 mm _{(0.157 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 19.09 mm Flange Diameter (FD): 22.2 mm Overall Length: 21.0 mm Hub Diameter (HD): 12.0
Part Number: P-050T-012-100FF-AS-N-040 Metric Timing Pulleys - 12 tooth - 10x4 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $39.32 AUD Regular price ~~$47.18 AUD~~ Sale price $39.32 AUD Unit price per Each
Teeth 12	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 4.000 mm _{(0.157 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 19.09 mm Flange Diameter (FD): 22.2 mm Overall Length: 21.0 mm Hub Diameter (HD): 12.0
Part Number: P-050T-012-100FF-AS-N-040 Metric Timing Pulleys - 12 tooth - 10x4 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $39.32 AUD Regular price ~~$47.18 AUD~~ Sale price $39.32 AUD Unit price per Each View the product page first if you are unsure.
P-050T-012-100FF-AS-N-040 --- Metric Timing Pulleys - 12 tooth - 10x4 mm - Aluminium with Steel Flanges Sale P-050T-012-100FF-AS-N-040 --- Metric Timing Pulleys - 12 tooth - 10x4 mm - Aluminium with Steel Flanges Regular price $39.32 AUD Regular price ~~$47.18 AUD~~ Sale price $39.32 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 14	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 4.000 mm _{(0.157 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 22.27 mm Flange Diameter (FD): 25.4 mm Overall Length: 21.0 mm Hub Diameter (HD): 14.0
Part Number: P-050T-014-100FF-AS-N-040 Metric Timing Pulleys - 14 tooth - 10x4 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $39.68 AUD Regular price ~~$47.62 AUD~~ Sale price $39.68 AUD Unit price per Each
Teeth 14	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 4.000 mm _{(0.157 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 22.27 mm Flange Diameter (FD): 25.4 mm Overall Length: 21.0 mm Hub Diameter (HD): 14.0
Part Number: P-050T-014-100FF-AS-N-040 Metric Timing Pulleys - 14 tooth - 10x4 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $39.68 AUD Regular price ~~$47.62 AUD~~ Sale price $39.68 AUD Unit price per Each View the product page first if you are unsure.
P-050T-014-100FF-AS-N-040 --- Metric Timing Pulleys - 14 tooth - 10x4 mm - Aluminium with Steel Flanges Sale P-050T-014-100FF-AS-N-040 --- Metric Timing Pulleys - 14 tooth - 10x4 mm - Aluminium with Steel Flanges Regular price $39.68 AUD Regular price ~~$47.62 AUD~~ Sale price $39.68 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 15	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Finished	Locking Type Set Screws (2)
Material: Aluminium Type: 2 Pitch Dia. (PD): 23.86 mm Flange Diameter (FD): 26.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 16.0
Part Number: P-050T-015-100FF-AL-G-060 Metric Timing Pulleys - 15 tooth - 10x6 mm - Aluminium 1 Available Immediately \| Item Discontinued - Up to 1 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $20.00 AUD Regular price ~~$38.00 AUD~~ Sale price $20.00 AUD Unit price per Each
Teeth 15	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Finished
Material: Aluminium Locking Type: Set Screws (2) Type: 2 Pitch Dia. (PD): 23.86 mm Flange Diameter (FD): 26.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 16.0
Part Number: P-050T-015-100FF-AL-G-060 Metric Timing Pulleys - 15 tooth - 10x6 mm - Aluminium 1 Available Immediately \| Item Discontinued - Up to 1 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $20.00 AUD Regular price ~~$38.00 AUD~~ Sale price $20.00 AUD Unit price per Each
P-050T-015-100FF-AL-G-060 --- Metric Timing Pulleys - 15 tooth - 10x6 mm - Aluminium Sale P-050T-015-100FF-AL-G-060 --- Metric Timing Pulleys - 15 tooth - 10x6 mm - Aluminium Regular price $20.00 AUD Regular price ~~$38.00 AUD~~ Sale price $20.00 AUD Unit price per 1 Available Now Sale
Teeth 15	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 23.86 mm Flange Diameter (FD): 27.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 16.0
Part Number: P-050T-015-100FF-AS-N-060 Metric Timing Pulleys - 15 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $40.14 AUD Regular price ~~$48.16 AUD~~ Sale price $40.14 AUD Unit price per Each
Teeth 15	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 23.86 mm Flange Diameter (FD): 27.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 16.0
Part Number: P-050T-015-100FF-AS-N-060 Metric Timing Pulleys - 15 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $40.14 AUD Regular price ~~$48.16 AUD~~ Sale price $40.14 AUD Unit price per Each View the product page first if you are unsure.
P-050T-015-100FF-AS-N-060 --- Metric Timing Pulleys - 15 tooth - 10x6 mm - Aluminium with Steel Flanges Sale P-050T-015-100FF-AS-N-060 --- Metric Timing Pulleys - 15 tooth - 10x6 mm - Aluminium with Steel Flanges Regular price $40.14 AUD Regular price ~~$48.16 AUD~~ Sale price $40.14 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 16	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 25.45 mm Flange Diameter (FD): 30.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 18.0
Part Number: P-050T-016-100FF-AS-N-060 Metric Timing Pulleys - 16 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $41.32 AUD Regular price ~~$49.58 AUD~~ Sale price $41.32 AUD Unit price per Each
Teeth 16	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 25.45 mm Flange Diameter (FD): 30.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 18.0
Part Number: P-050T-016-100FF-AS-N-060 Metric Timing Pulleys - 16 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $41.32 AUD Regular price ~~$49.58 AUD~~ Sale price $41.32 AUD Unit price per Each View the product page first if you are unsure.
P-050T-016-100FF-AS-N-060 --- Metric Timing Pulleys - 16 tooth - 10x6 mm - Aluminium with Steel Flanges Sale P-050T-016-100FF-AS-N-060 --- Metric Timing Pulleys - 16 tooth - 10x6 mm - Aluminium with Steel Flanges Regular price $41.32 AUD Regular price ~~$49.58 AUD~~ Sale price $41.32 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 18	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 28.64 mm Flange Diameter (FD): 33.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 20.0
Part Number: P-050T-018-100FF-AS-N-060 Metric Timing Pulleys - 18 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $42.50 AUD Regular price ~~$51.00 AUD~~ Sale price $42.50 AUD Unit price per Each
Teeth 18	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 28.64 mm Flange Diameter (FD): 33.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 20.0
Part Number: P-050T-018-100FF-AS-N-060 Metric Timing Pulleys - 18 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $42.50 AUD Regular price ~~$51.00 AUD~~ Sale price $42.50 AUD Unit price per Each View the product page first if you are unsure.
P-050T-018-100FF-AS-N-060 --- Metric Timing Pulleys - 18 tooth - 10x6 mm - Aluminium with Steel Flanges Sale P-050T-018-100FF-AS-N-060 --- Metric Timing Pulleys - 18 tooth - 10x6 mm - Aluminium with Steel Flanges Regular price $42.50 AUD Regular price ~~$51.00 AUD~~ Sale price $42.50 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 20	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 31.82 mm Flange Diameter (FD): 35.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 24.0
Part Number: P-050T-020-100FF-AS-N-060 Metric Timing Pulleys - 20 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $45.68 AUD Regular price ~~$54.82 AUD~~ Sale price $45.68 AUD Unit price per Each
Teeth 20	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 31.82 mm Flange Diameter (FD): 35.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 24.0
Part Number: P-050T-020-100FF-AS-N-060 Metric Timing Pulleys - 20 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $45.68 AUD Regular price ~~$54.82 AUD~~ Sale price $45.68 AUD Unit price per Each View the product page first if you are unsure.
P-050T-020-100FF-AS-N-060 --- Metric Timing Pulleys - 20 tooth - 10x6 mm - Aluminium with Steel Flanges Sale P-050T-020-100FF-AS-N-060 --- Metric Timing Pulleys - 20 tooth - 10x6 mm - Aluminium with Steel Flanges Regular price $45.68 AUD Regular price ~~$54.82 AUD~~ Sale price $45.68 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 22	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 35.00 mm Flange Diameter (FD): 38.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 25.0
Part Number: P-050T-022-100FF-AS-N-060 Metric Timing Pulleys - 22 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $47.32 AUD Regular price ~~$56.78 AUD~~ Sale price $47.32 AUD Unit price per Each
Teeth 22	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 35.00 mm Flange Diameter (FD): 38.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 25.0
Part Number: P-050T-022-100FF-AS-N-060 Metric Timing Pulleys - 22 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $47.32 AUD Regular price ~~$56.78 AUD~~ Sale price $47.32 AUD Unit price per Each View the product page first if you are unsure.
P-050T-022-100FF-AS-N-060 --- Metric Timing Pulleys - 22 tooth - 10x6 mm - Aluminium with Steel Flanges Sale P-050T-022-100FF-AS-N-060 --- Metric Timing Pulleys - 22 tooth - 10x6 mm - Aluminium with Steel Flanges Regular price $47.32 AUD Regular price ~~$56.78 AUD~~ Sale price $47.32 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 24	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 38.18 mm Flange Diameter (FD): 41.3 mm Overall Length: 21.0 mm Hub Diameter (HD): 26.0
Part Number: P-050T-024-100FF-AS-N-060 Metric Timing Pulleys - 24 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $48.14 AUD Regular price ~~$57.76 AUD~~ Sale price $48.14 AUD Unit price per Each
Teeth 24	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 38.18 mm Flange Diameter (FD): 41.3 mm Overall Length: 21.0 mm Hub Diameter (HD): 26.0
Part Number: P-050T-024-100FF-AS-N-060 Metric Timing Pulleys - 24 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $48.14 AUD Regular price ~~$57.76 AUD~~ Sale price $48.14 AUD Unit price per Each View the product page first if you are unsure.
P-050T-024-100FF-AS-N-060 --- Metric Timing Pulleys - 24 tooth - 10x6 mm - Aluminium with Steel Flanges Sale P-050T-024-100FF-AS-N-060 --- Metric Timing Pulleys - 24 tooth - 10x6 mm - Aluminium with Steel Flanges Regular price $48.14 AUD Regular price ~~$57.76 AUD~~ Sale price $48.14 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 25	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 39.77 mm Flange Diameter (FD): 43.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 26.0
Part Number: P-050T-025-100FF-AS-N-060 Metric Timing Pulleys - 25 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $48.59 AUD Regular price ~~$58.31 AUD~~ Sale price $48.59 AUD Unit price per Each
Teeth 25	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 39.77 mm Flange Diameter (FD): 43.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 26.0
Part Number: P-050T-025-100FF-AS-N-060 Metric Timing Pulleys - 25 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $48.59 AUD Regular price ~~$58.31 AUD~~ Sale price $48.59 AUD Unit price per Each View the product page first if you are unsure.
P-050T-025-100FF-AS-N-060 --- Metric Timing Pulleys - 25 tooth - 10x6 mm - Aluminium with Steel Flanges Sale P-050T-025-100FF-AS-N-060 --- Metric Timing Pulleys - 25 tooth - 10x6 mm - Aluminium with Steel Flanges Regular price $48.59 AUD Regular price ~~$58.31 AUD~~ Sale price $48.59 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 25	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Finished	Locking Type Set Screws (2)
Material: Aluminium Type: 2 Pitch Dia. (PD): 39.77 mm Flange Diameter (FD): 44.5 mm Overall Length: 21.0 mm Hub Diameter (HD): 26.0
Part Number: P-050T-025-100FF-AL-G-060 Metric Timing Pulleys - 25 tooth - 10x6 mm - Aluminium Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Teeth 25	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Finished
Material: Aluminium Locking Type: Set Screws (2) Type: 2 Pitch Dia. (PD): 39.77 mm Flange Diameter (FD): 44.5 mm Overall Length: 21.0 mm Hub Diameter (HD): 26.0
Part Number: P-050T-025-100FF-AL-G-060 Metric Timing Pulleys - 25 tooth - 10x6 mm - Aluminium Contact Us \| Item Discontinued - Please contact us if you need a large quantity
Teeth 26	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 41.36 mm Flange Diameter (FD): 44.5 mm Overall Length: 21.0 mm Hub Diameter (HD): 26.0
Part Number: P-050T-026-100FF-AS-N-060 Metric Timing Pulleys - 26 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $49.41 AUD Regular price ~~$59.29 AUD~~ Sale price $49.41 AUD Unit price per Each
Teeth 26	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 41.36 mm Flange Diameter (FD): 44.5 mm Overall Length: 21.0 mm Hub Diameter (HD): 26.0
Part Number: P-050T-026-100FF-AS-N-060 Metric Timing Pulleys - 26 tooth - 10x6 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $49.41 AUD Regular price ~~$59.29 AUD~~ Sale price $49.41 AUD Unit price per Each View the product page first if you are unsure.
P-050T-026-100FF-AS-N-060 --- Metric Timing Pulleys - 26 tooth - 10x6 mm - Aluminium with Steel Flanges Sale P-050T-026-100FF-AS-N-060 --- Metric Timing Pulleys - 26 tooth - 10x6 mm - Aluminium with Steel Flanges Regular price $49.41 AUD Regular price ~~$59.29 AUD~~ Sale price $49.41 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 27	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 42.95 mm Flange Diameter (FD): 46.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 30.0
Part Number: P-050T-027-100FF-AS-N-080 Metric Timing Pulleys - 27 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $50.95 AUD Regular price ~~$61.15 AUD~~ Sale price $50.95 AUD Unit price per Each
Teeth 27	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 42.95 mm Flange Diameter (FD): 46.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 30.0
Part Number: P-050T-027-100FF-AS-N-080 Metric Timing Pulleys - 27 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $50.95 AUD Regular price ~~$61.15 AUD~~ Sale price $50.95 AUD Unit price per Each View the product page first if you are unsure.
P-050T-027-100FF-AS-N-080 --- Metric Timing Pulleys - 27 tooth - 10x8 mm - Aluminium with Steel Flanges Sale P-050T-027-100FF-AS-N-080 --- Metric Timing Pulleys - 27 tooth - 10x8 mm - Aluminium with Steel Flanges Regular price $50.95 AUD Regular price ~~$61.15 AUD~~ Sale price $50.95 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 30	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 47.73 mm Flange Diameter (FD): 51.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 34.0
Part Number: P-050T-030-100FF-AS-N-080 Metric Timing Pulleys - 30 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $51.41 AUD Regular price ~~$61.69 AUD~~ Sale price $51.41 AUD Unit price per Each
Teeth 30	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 47.73 mm Flange Diameter (FD): 51.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 34.0
Part Number: P-050T-030-100FF-AS-N-080 Metric Timing Pulleys - 30 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $51.41 AUD Regular price ~~$61.69 AUD~~ Sale price $51.41 AUD Unit price per Each View the product page first if you are unsure.
P-050T-030-100FF-AS-N-080 --- Metric Timing Pulleys - 30 tooth - 10x8 mm - Aluminium with Steel Flanges Sale P-050T-030-100FF-AS-N-080 --- Metric Timing Pulleys - 30 tooth - 10x8 mm - Aluminium with Steel Flanges Regular price $51.41 AUD Regular price ~~$61.69 AUD~~ Sale price $51.41 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 32	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 50.91 mm Flange Diameter (FD): 54.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 38.0
Part Number: P-050T-032-100FF-AS-N-080 Metric Timing Pulleys - 32 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $57.41 AUD Regular price ~~$68.89 AUD~~ Sale price $57.41 AUD Unit price per Each
Teeth 32	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 50.91 mm Flange Diameter (FD): 54.0 mm Overall Length: 21.0 mm Hub Diameter (HD): 38.0
Part Number: P-050T-032-100FF-AS-N-080 Metric Timing Pulleys - 32 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $57.41 AUD Regular price ~~$68.89 AUD~~ Sale price $57.41 AUD Unit price per Each View the product page first if you are unsure.
P-050T-032-100FF-AS-N-080 --- Metric Timing Pulleys - 32 tooth - 10x8 mm - Aluminium with Steel Flanges Sale P-050T-032-100FF-AS-N-080 --- Metric Timing Pulleys - 32 tooth - 10x8 mm - Aluminium with Steel Flanges Regular price $57.41 AUD Regular price ~~$68.89 AUD~~ Sale price $57.41 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 36	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 57.27 mm Flange Diameter (FD): 60.3 mm Overall Length: 21.0 mm Hub Diameter (HD): 38.0
Part Number: P-050T-036-100FF-AS-N-080 Metric Timing Pulleys - 36 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $60.59 AUD Regular price ~~$72.71 AUD~~ Sale price $60.59 AUD Unit price per Each
Teeth 36	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 57.27 mm Flange Diameter (FD): 60.3 mm Overall Length: 21.0 mm Hub Diameter (HD): 38.0
Part Number: P-050T-036-100FF-AS-N-080 Metric Timing Pulleys - 36 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $60.59 AUD Regular price ~~$72.71 AUD~~ Sale price $60.59 AUD Unit price per Each View the product page first if you are unsure.
P-050T-036-100FF-AS-N-080 --- Metric Timing Pulleys - 36 tooth - 10x8 mm - Aluminium with Steel Flanges Sale P-050T-036-100FF-AS-N-080 --- Metric Timing Pulleys - 36 tooth - 10x8 mm - Aluminium with Steel Flanges Regular price $60.59 AUD Regular price ~~$72.71 AUD~~ Sale price $60.59 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 40	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 2 Pitch Dia. (PD): 63.63 mm Flange Diameter (FD): 66.7 mm Overall Length: 21.0 mm Hub Diameter (HD): 40.0
Part Number: P-050T-040-100FF-AS-N-080 Metric Timing Pulleys - 40 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $77.50 AUD Regular price ~~$93.00 AUD~~ Sale price $77.50 AUD Unit price per Each
Teeth 40	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 2 Pitch Dia. (PD): 63.63 mm Flange Diameter (FD): 66.7 mm Overall Length: 21.0 mm Hub Diameter (HD): 40.0
Part Number: P-050T-040-100FF-AS-N-080 Metric Timing Pulleys - 40 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $77.50 AUD Regular price ~~$93.00 AUD~~ Sale price $77.50 AUD Unit price per Each View the product page first if you are unsure.
P-050T-040-100FF-AS-N-080 --- Metric Timing Pulleys - 40 tooth - 10x8 mm - Aluminium with Steel Flanges Sale P-050T-040-100FF-AS-N-080 --- Metric Timing Pulleys - 40 tooth - 10x8 mm - Aluminium with Steel Flanges Regular price $77.50 AUD Regular price ~~$93.00 AUD~~ Sale price $77.50 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 48	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 3 Pitch Dia. (PD): 76.36 mm Overall Length: 21.0 mm Hub Diameter (HD): 50.0
Part Number: P-050T-048-100P-AS-N-080 Metric Timing Pulleys - 48 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $86.68 AUD Regular price ~~$104.02 AUD~~ Sale price $86.68 AUD Unit price per Each
Teeth 48	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 3 Pitch Dia. (PD): 76.36 mm Overall Length: 21.0 mm Hub Diameter (HD): 50.0
Part Number: P-050T-048-100P-AS-N-080 Metric Timing Pulleys - 48 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $86.68 AUD Regular price ~~$104.02 AUD~~ Sale price $86.68 AUD Unit price per Each View the product page first if you are unsure.
P-050T-048-100P-AS-N-080 --- Metric Timing Pulleys - 48 tooth - 10x8 mm - Aluminium with Steel Flanges Sale P-050T-048-100P-AS-N-080 --- Metric Timing Pulleys - 48 tooth - 10x8 mm - Aluminium with Steel Flanges Regular price $86.68 AUD Regular price ~~$104.02 AUD~~ Sale price $86.68 AUD Unit price per Out of stock! Backorder Now Sale
Teeth 60	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain	Locking Type None
Material: Aluminium with Steel Flanges Type: 3 Pitch Dia. (PD): 95.45 mm Overall Length: 21.0 mm Hub Diameter (HD): 65.0
Part Number: P-050T-060-100P-AS-N-080 Metric Timing Pulleys - 60 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $106.77 AUD Regular price ~~$128.13 AUD~~ Sale price $106.77 AUD Unit price per Each
Teeth 60	Max Belt Width 10.00 mm _{(0.394 in.)}	Bore (d) 8.000 mm _{(0.315 in.)}	Bore Type Plain
Material: Aluminium with Steel Flanges Locking Type: None Type: 3 Pitch Dia. (PD): 95.45 mm Overall Length: 21.0 mm Hub Diameter (HD): 65.0
Part Number: P-050T-060-100P-AS-N-080 Metric Timing Pulleys - 60 tooth - 10x8 mm - Aluminium with Steel Flanges Out of Stock \| Backorder Now \| Orders can be expected around Sun, Jul 06, 2025 Regular price $106.77 AUD Regular price ~~$128.13 AUD~~ Sale price $106.77 AUD Unit price per Each View the product page first if you are unsure.
P-050T-060-100P-AS-N-080 --- Metric Timing Pulleys - 60 tooth - 10x8 mm - Aluminium with Steel Flanges Sale P-050T-060-100P-AS-N-080 --- Metric Timing Pulleys - 60 tooth - 10x8 mm - Aluminium with Steel Flanges Regular price $106.77 AUD Regular price ~~$128.13 AUD~~ Sale price $106.77 AUD Unit price per Out of stock! Backorder Now Sale
