Mounts - Machinery Industrial - Medium Duty

3 Products in this selection
  • High strength machined components. Rapid installation and leveling. 80% vibration reduction. Vertical and horizontal isolation.
  • For milling mchines, presses, injection molding, packaging machines.
  • Industrial machine mount designed with high strength construction for reduction of both shock and vibration.
  • Prevents vibration from affecting other machines and protects mounted equipment from external vibration effects.
  • Provides precision leveling with large support plate and meets OSHA standards by preventing machinery walking.
Additional resources:
Cylindrical Bobbin Mounts PDF Quick Guide
A more concise listing may be found on the Smallparts store at Mounts - Machinery Industrial - Medium Duty. Smallparts promote the most popular MBA products.
Load Base Diameter Overall Length Height Adjustment Thread Size Indicative
498.9
Kg 		80.010
mm 		38.100
mm 		128.524
mm 		11.938
mm 		M12.0 x 1.25 (12.0mm)
1219781 | MMI-0499-M --- Machinery Industrial Mounts - 498.9 Kg - 80.01x38.1 mm - Rubber and Steel
Material: Rubber and Steel    Thread Length: 120.650 mm    Non-Impact Machinery Load: 498.951 Kg    125 Strokes per Min Load: 199.580 Kg    180 Strokes per Min Load: 136.078 Kg    200 Strokes per Min Load: 117.934 Kg    Injection Molding: 176.901 Kg
Part Number: MMI-0499-M Machinery Industrial Mounts - 498.9 Kg - 80.01x38.1 mm - Rubber and Steel
Out of Stock | Backorder Now | Orders can be expected around Thu, May 15, 2025
$218.68 AUD
$218.68 AUD
Each
Load Base Diameter Overall Length Height Indicative
498.9
Kg 		80.010
mm 		38.100
mm 		128.524
mm 		1219781 | MMI-0499-M --- Machinery Industrial Mounts - 498.9 Kg - 80.01x38.1 mm - Rubber and Steel
Material: Rubber and Steel    Adjustment: 11.938 mm    Thread Size: M12.0 x 1.25 (12.0mm)    Thread Length: 120.650 mm    Non-Impact Machinery Load: 498.951 Kg    125 Strokes per Min Load: 199.580 Kg    180 Strokes per Min Load: 136.078 Kg    200 Strokes per Min Load: 117.934 Kg    Injection Molding: 176.901 Kg
Part Number: MMI-0499-M Machinery Industrial Mounts - 498.9 Kg - 80.01x38.1 mm - Rubber and Steel
Out of Stock | Backorder Now | Orders can be expected around Thu, May 15, 2025
$218.68 AUD
$218.68 AUD
Each
View the product page first if you are unsure.
997.9
Kg 		120.650
mm 		45.974
mm 		128.524
mm 		12.954
mm 		M16.0 x 1.50 (16.0mm)
1221723 | MMI-0998-M --- Machinery Industrial Mounts - 997.9 Kg - 120.65x45.974 mm - Rubber and Steel
Material: Rubber and Steel    Thread Length: 120.650 mm    Non-Impact Machinery Load: 997.902 Kg    125 Strokes per Min Load: 399.161 Kg    180 Strokes per Min Load: 349.266 Kg    200 Strokes per Min Load: 249.476 Kg    Injection Molding: 358.338 Kg
Part Number: MMI-0998-M Machinery Industrial Mounts - 997.9 Kg - 120.65x45.974 mm - Rubber and Steel
Out of Stock | Backorder Now | Orders can be expected around Thu, May 15, 2025
$428.41 AUD
$428.41 AUD
Each
997.9
Kg 		120.650
mm 		45.974
mm 		128.524
mm 		1221723 | MMI-0998-M --- Machinery Industrial Mounts - 997.9 Kg - 120.65x45.974 mm - Rubber and Steel
Material: Rubber and Steel    Adjustment: 12.954 mm    Thread Size: M16.0 x 1.50 (16.0mm)    Thread Length: 120.650 mm    Non-Impact Machinery Load: 997.902 Kg    125 Strokes per Min Load: 399.161 Kg    180 Strokes per Min Load: 349.266 Kg    200 Strokes per Min Load: 249.476 Kg    Injection Molding: 358.338 Kg
Part Number: MMI-0998-M Machinery Industrial Mounts - 997.9 Kg - 120.65x45.974 mm - Rubber and Steel
Out of Stock | Backorder Now | Orders can be expected around Thu, May 15, 2025
$428.41 AUD
$428.41 AUD
Each
View the product page first if you are unsure.
2494.7
Kg 		158.750
mm 		53.086
mm 		188.468
mm 		14.986
mm 		M20.0 x 1.50 (20.0mm)
1223361 | MMI-2495-M --- Machinery Industrial Mounts - 2494.7 Kg - 158.75x53.086 mm - Rubber and Steel
Material: Rubber and Steel    Thread Length: 168.275 mm    Non-Impact Machinery Load: 2494.756 Kg    125 Strokes per Min Load: 1397.063 Kg    180 Strokes per Min Load: 1097.693 Kg    200 Strokes per Min Load: 798.322 Kg    Injection Molding: 988.831 Kg
Part Number: MMI-2495-M Machinery Industrial Mounts - 2494.7 Kg - 158.75x53.086 mm - Rubber and Steel
Out of Stock | Backorder Now | Orders can be expected around Thu, May 15, 2025
$720.86 AUD
$720.86 AUD
Each
2494.7
Kg 		158.750
mm 		53.086
mm 		188.468
mm 		1223361 | MMI-2495-M --- Machinery Industrial Mounts - 2494.7 Kg - 158.75x53.086 mm - Rubber and Steel
Material: Rubber and Steel    Adjustment: 14.986 mm    Thread Size: M20.0 x 1.50 (20.0mm)    Thread Length: 168.275 mm    Non-Impact Machinery Load: 2494.756 Kg    125 Strokes per Min Load: 1397.063 Kg    180 Strokes per Min Load: 1097.693 Kg    200 Strokes per Min Load: 798.322 Kg    Injection Molding: 988.831 Kg
Part Number: MMI-2495-M Machinery Industrial Mounts - 2494.7 Kg - 158.75x53.086 mm - Rubber and Steel
Out of Stock | Backorder Now | Orders can be expected around Thu, May 15, 2025
$720.86 AUD
$720.86 AUD
Each
View the product page first if you are unsure.
