Collection: Linear - Rail Systems Miniature Profile

Linear (With Images)

Rail Systems Miniature Profile

19 Products in this selection

Ideal for precision applications where mounting space is limited
Gothic arch grooves at raceway contacts enables slide to sustain loads & movement from any direction.
Made from stainless steel or plastic for corrosion resistance. End caps have oil holes for easy relubrication.

Additional resources:

A more concise listing may be found on the Smallparts store at Linear - Rail Systems Miniature Profile. Smallparts promote the most popular MBA products.

Load	No. Of Carriages	Rail Length (L)	Carriage Length (F/D)	Rail Dimensions (J/K)	Carriage Dimensions (A/B)
188.69 Kg	1.00	80.00 mm	32.00 / 21.50 mm	6.50 / 9.00 mm	10.00 / 20.00 mm
P: 3.50 mm Rail Bolt Distance (R): 60.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF0RS Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 80 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $452.32 AUD Regular price Sale price $452.32 AUD Unit price per Each
Load	No. Of Carriages	Rail Length (L)	Carriage Length (F/D)	Indicative Image
188.69 Kg	1.00	80.00 mm	32.00 / 21.50 mm
Rail Dimensions (J/K): 6.50 / 9.00 mm Carriage Dimensions (A/B): 10.00 / 20.00 mm P: 3.50 mm Rail Bolt Distance (R): 60.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF0RS Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 80 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $452.32 AUD Regular price Sale price $452.32 AUD Unit price per Each View the product page first if you are unsure.
SKF0RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 80 mm SKF0RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 80 mm Regular price $452.32 AUD Regular price Sale price $452.32 AUD Unit price per Out of stock! Backorder Now
188.69 Kg	1.00	110.00 mm	32.00 / 21.50 mm	6.50 / 9.00 mm	10.00 / 20.00 mm
P: 3.50 mm Rail Bolt Distance (R): 80.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF1RS Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 110 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $421.14 AUD Regular price Sale price $421.14 AUD Unit price per Each
188.69 Kg	1.00	110.00 mm	32.00 / 21.50 mm
Rail Dimensions (J/K): 6.50 / 9.00 mm Carriage Dimensions (A/B): 10.00 / 20.00 mm P: 3.50 mm Rail Bolt Distance (R): 80.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF1RS Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 110 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $421.14 AUD Regular price Sale price $421.14 AUD Unit price per Each View the product page first if you are unsure.
SKF1RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 110 mm SKF1RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 110 mm Regular price $421.14 AUD Regular price Sale price $421.14 AUD Unit price per Out of stock! Backorder Now
188.69 Kg	1.00	140.00 mm	32.00 / 21.50 mm	6.50 / 9.00 mm	10.00 / 20.00 mm
P: 3.50 mm Rail Bolt Distance (R): 120.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF3RS Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 140 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $635.59 AUD Regular price Sale price $635.59 AUD Unit price per Each
188.69 Kg	1.00	140.00 mm	32.00 / 21.50 mm
Rail Dimensions (J/K): 6.50 / 9.00 mm Carriage Dimensions (A/B): 10.00 / 20.00 mm P: 3.50 mm Rail Bolt Distance (R): 120.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF3RS Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 140 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $635.59 AUD Regular price Sale price $635.59 AUD Unit price per Each View the product page first if you are unsure.
SKF3RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 140 mm SKF3RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 140 mm Regular price $635.59 AUD Regular price Sale price $635.59 AUD Unit price per Out of stock! Backorder Now
188.69 Kg	1.00	170.00 mm	32.00 / 21.50 mm	6.50 / 9.00 mm	10.00 / 20.00 mm
P: 3.50 mm Rail Bolt Distance (R): 140.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF5RS Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 170 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $661.95 AUD Regular price Sale price $661.95 AUD Unit price per Each
188.69 Kg	1.00	170.00 mm	32.00 / 21.50 mm
Rail Dimensions (J/K): 6.50 / 9.00 mm Carriage Dimensions (A/B): 10.00 / 20.00 mm P: 3.50 mm Rail Bolt Distance (R): 140.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF5RS Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 170 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $661.95 AUD Regular price Sale price $661.95 AUD Unit price per Each View the product page first if you are unsure.
SKF5RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 170 mm SKF5RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 1 - 170 mm Regular price $661.95 AUD Regular price Sale price $661.95 AUD Unit price per Out of stock! Backorder Now
188.69 Kg	2.00	110.00 mm	32.00 / 21.50 mm	6.50 / 9.00 mm	10.00 / 20.00 mm
P: 3.50 mm Rail Bolt Distance (R): 80.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF2RS Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 110 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $833.41 AUD Regular price Sale price $833.41 AUD Unit price per Each
188.69 Kg	2.00	110.00 mm	32.00 / 21.50 mm
Rail Dimensions (J/K): 6.50 / 9.00 mm Carriage Dimensions (A/B): 10.00 / 20.00 mm P: 3.50 mm Rail Bolt Distance (R): 80.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF2RS Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 110 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $833.41 AUD Regular price Sale price $833.41 AUD Unit price per Each View the product page first if you are unsure.
SKF2RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 110 mm SKF2RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 110 mm Regular price $833.41 AUD Regular price Sale price $833.41 AUD Unit price per Out of stock! Backorder Now
188.69 Kg	2.00	140.00 mm	32.00 / 21.50 mm	6.50 / 9.00 mm	10.00 / 20.00 mm
P: 3.50 mm Rail Bolt Distance (R): 120.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF4RS Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 140 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $861.50 AUD Regular price Sale price $861.50 AUD Unit price per Each
188.69 Kg	2.00	140.00 mm	32.00 / 21.50 mm
Rail Dimensions (J/K): 6.50 / 9.00 mm Carriage Dimensions (A/B): 10.00 / 20.00 mm P: 3.50 mm Rail Bolt Distance (R): 120.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF4RS Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 140 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $861.50 AUD Regular price Sale price $861.50 AUD Unit price per Each View the product page first if you are unsure.
SKF4RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 140 mm SKF4RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 140 mm Regular price $861.50 AUD Regular price Sale price $861.50 AUD Unit price per Out of stock! Backorder Now
188.69 Kg	2.00	170.00 mm	32.00 / 21.50 mm	6.50 / 9.00 mm	10.00 / 20.00 mm
P: 3.50 mm Rail Bolt Distance (R): 140.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF6RS Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 170 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $889.95 AUD Regular price Sale price $889.95 AUD Unit price per Each
188.69 Kg	2.00	170.00 mm	32.00 / 21.50 mm
Rail Dimensions (J/K): 6.50 / 9.00 mm Carriage Dimensions (A/B): 10.00 / 20.00 mm P: 3.50 mm Rail Bolt Distance (R): 140.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF6RS Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 170 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $889.95 AUD Regular price Sale price $889.95 AUD Unit price per Each View the product page first if you are unsure.
SKF6RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 170 mm SKF6RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 170 mm Regular price $889.95 AUD Regular price Sale price $889.95 AUD Unit price per Out of stock! Backorder Now
188.69 Kg	2.00	200.00 mm	32.00 / 21.50 mm	6.50 / 9.00 mm	10.00 / 20.00 mm
P: 3.50 mm Rail Bolt Distance (R): 180.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF7RS Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 200 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $922.32 AUD Regular price Sale price $922.32 AUD Unit price per Each
188.69 Kg	2.00	200.00 mm	32.00 / 21.50 mm
Rail Dimensions (J/K): 6.50 / 9.00 mm Carriage Dimensions (A/B): 10.00 / 20.00 mm P: 3.50 mm Rail Bolt Distance (R): 180.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF7RS Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 200 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $922.32 AUD Regular price Sale price $922.32 AUD Unit price per Each View the product page first if you are unsure.
SKF7RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 200 mm SKF7RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 200 mm Regular price $922.32 AUD Regular price Sale price $922.32 AUD Unit price per Out of stock! Backorder Now
188.69 Kg	2.00	260.00 mm	32.00 / 21.50 mm	6.50 / 9.00 mm	10.00 / 20.00 mm
P: 3.50 mm Rail Bolt Distance (R): 240.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF8RS Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 260 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $971.50 AUD Regular price Sale price $971.50 AUD Unit price per Each
188.69 Kg	2.00	260.00 mm	32.00 / 21.50 mm
Rail Dimensions (J/K): 6.50 / 9.00 mm Carriage Dimensions (A/B): 10.00 / 20.00 mm P: 3.50 mm Rail Bolt Distance (R): 240.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF8RS Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 260 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $971.50 AUD Regular price Sale price $971.50 AUD Unit price per Each View the product page first if you are unsure.
SKF8RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 260 mm SKF8RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 260 mm Regular price $971.50 AUD Regular price Sale price $971.50 AUD Unit price per Out of stock! Backorder Now
188.69 Kg	2.00	290.00 mm	32.00 / 21.50 mm	6.50 / 9.00 mm	10.00 / 20.00 mm
P: 3.50 mm Rail Bolt Distance (R): 260.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF9RS Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 290 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $998.50 AUD Regular price Sale price $998.50 AUD Unit price per Each
188.69 Kg	2.00	290.00 mm	32.00 / 21.50 mm
Rail Dimensions (J/K): 6.50 / 9.00 mm Carriage Dimensions (A/B): 10.00 / 20.00 mm P: 3.50 mm Rail Bolt Distance (R): 260.00 mm Rail Bolt Distance (Q): 20.00 mm Carriage Bolt Distance (C): 15.00 mm Carriage Bolt Distance (E): 10.00 mm More Information: For more information please contact us
Part Number: SKF9RS Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 290 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $998.50 AUD Regular price Sale price $998.50 AUD Unit price per Each View the product page first if you are unsure.
SKF9RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 290 mm SKF9RS --- Rail Systems Miniature Profile Linear - 188.69 Kg - 2 - 290 mm Regular price $998.50 AUD Regular price Sale price $998.50 AUD Unit price per Out of stock! Backorder Now
259.91 Kg	1.00	110.00 mm	36.00 / 23.00 mm	8.80 / 12.00 mm	13.00 / 27.00 mm
P: 4.50 mm Rail Bolt Distance (R): 75.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF10RS Rail Systems Miniature Profile Linear - 259.91 Kg - 1 - 110 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $533.68 AUD Regular price Sale price $533.68 AUD Unit price per Each
259.91 Kg	1.00	110.00 mm	36.00 / 23.00 mm
Rail Dimensions (J/K): 8.80 / 12.00 mm Carriage Dimensions (A/B): 13.00 / 27.00 mm P: 4.50 mm Rail Bolt Distance (R): 75.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF10RS Rail Systems Miniature Profile Linear - 259.91 Kg - 1 - 110 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $533.68 AUD Regular price Sale price $533.68 AUD Unit price per Each View the product page first if you are unsure.
SKF10RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 1 - 110 mm SKF10RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 1 - 110 mm Regular price $533.68 AUD Regular price Sale price $533.68 AUD Unit price per Out of stock! Backorder Now
259.91 Kg	1.00	190.00 mm	36.00 / 23.00 mm	8.80 / 12.00 mm	13.00 / 27.00 mm
P: 4.50 mm Rail Bolt Distance (R): 150.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF13RS Rail Systems Miniature Profile Linear - 259.91 Kg - 1 - 190 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $747.77 AUD Regular price Sale price $747.77 AUD Unit price per Each
259.91 Kg	1.00	190.00 mm	36.00 / 23.00 mm
Rail Dimensions (J/K): 8.80 / 12.00 mm Carriage Dimensions (A/B): 13.00 / 27.00 mm P: 4.50 mm Rail Bolt Distance (R): 150.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF13RS Rail Systems Miniature Profile Linear - 259.91 Kg - 1 - 190 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $747.77 AUD Regular price Sale price $747.77 AUD Unit price per Each View the product page first if you are unsure.
SKF13RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 1 - 190 mm SKF13RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 1 - 190 mm Regular price $747.77 AUD Regular price Sale price $747.77 AUD Unit price per Out of stock! Backorder Now
259.91 Kg	1.00	230.00 mm	36.00 / 23.00 mm	8.80 / 12.00 mm	13.00 / 27.00 mm
P: 4.50 mm Rail Bolt Distance (R): 200.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF15RS Rail Systems Miniature Profile Linear - 259.91 Kg - 1 - 230 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $789.50 AUD Regular price Sale price $789.50 AUD Unit price per Each
259.91 Kg	1.00	230.00 mm	36.00 / 23.00 mm
Rail Dimensions (J/K): 8.80 / 12.00 mm Carriage Dimensions (A/B): 13.00 / 27.00 mm P: 4.50 mm Rail Bolt Distance (R): 200.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF15RS Rail Systems Miniature Profile Linear - 259.91 Kg - 1 - 230 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $789.50 AUD Regular price Sale price $789.50 AUD Unit price per Each View the product page first if you are unsure.
SKF15RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 1 - 230 mm SKF15RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 1 - 230 mm Regular price $789.50 AUD Regular price Sale price $789.50 AUD Unit price per Out of stock! Backorder Now
259.91 Kg	2.00	150.00 mm	36.00 / 23.00 mm	8.80 / 12.00 mm	13.00 / 27.00 mm
P: 4.50 mm Rail Bolt Distance (R): 125.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF12RS Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 150 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $959.59 AUD Regular price Sale price $959.59 AUD Unit price per Each
259.91 Kg	2.00	150.00 mm	36.00 / 23.00 mm
Rail Dimensions (J/K): 8.80 / 12.00 mm Carriage Dimensions (A/B): 13.00 / 27.00 mm P: 4.50 mm Rail Bolt Distance (R): 125.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF12RS Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 150 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $959.59 AUD Regular price Sale price $959.59 AUD Unit price per Each View the product page first if you are unsure.
SKF12RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 150 mm SKF12RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 150 mm Regular price $959.59 AUD Regular price Sale price $959.59 AUD Unit price per Out of stock! Backorder Now
259.91 Kg	2.00	190.00 mm	36.00 / 23.00 mm	8.80 / 12.00 mm	13.00 / 27.00 mm
P: 4.50 mm Rail Bolt Distance (R): 150.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF14RS Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 190 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $1,003.23 AUD Regular price Sale price $1,003.23 AUD Unit price per Each
259.91 Kg	2.00	190.00 mm	36.00 / 23.00 mm
Rail Dimensions (J/K): 8.80 / 12.00 mm Carriage Dimensions (A/B): 13.00 / 27.00 mm P: 4.50 mm Rail Bolt Distance (R): 150.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF14RS Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 190 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $1,003.23 AUD Regular price Sale price $1,003.23 AUD Unit price per Each View the product page first if you are unsure.
SKF14RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 190 mm SKF14RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 190 mm Regular price $1,003.23 AUD Regular price Sale price $1,003.23 AUD Unit price per Out of stock! Backorder Now
259.91 Kg	2.00	230.00 mm	36.00 / 23.00 mm	8.80 / 12.00 mm	13.00 / 27.00 mm
P: 4.50 mm Rail Bolt Distance (R): 200.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF16RS Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 230 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $1,045.23 AUD Regular price Sale price $1,045.23 AUD Unit price per Each
259.91 Kg	2.00	230.00 mm	36.00 / 23.00 mm
Rail Dimensions (J/K): 8.80 / 12.00 mm Carriage Dimensions (A/B): 13.00 / 27.00 mm P: 4.50 mm Rail Bolt Distance (R): 200.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF16RS Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 230 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $1,045.23 AUD Regular price Sale price $1,045.23 AUD Unit price per Each View the product page first if you are unsure.
SKF16RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 230 mm SKF16RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 230 mm Regular price $1,045.23 AUD Regular price Sale price $1,045.23 AUD Unit price per Out of stock! Backorder Now
259.91 Kg	2.00	310.00 mm	36.00 / 23.00 mm	8.80 / 12.00 mm	13.00 / 27.00 mm
P: 4.50 mm Rail Bolt Distance (R): 275.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF17RS Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 310 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $1,128.77 AUD Regular price Sale price $1,128.77 AUD Unit price per Each
259.91 Kg	2.00	310.00 mm	36.00 / 23.00 mm
Rail Dimensions (J/K): 8.80 / 12.00 mm Carriage Dimensions (A/B): 13.00 / 27.00 mm P: 4.50 mm Rail Bolt Distance (R): 275.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF17RS Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 310 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $1,128.77 AUD Regular price Sale price $1,128.77 AUD Unit price per Each View the product page first if you are unsure.
SKF17RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 310 mm SKF17RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 310 mm Regular price $1,128.77 AUD Regular price Sale price $1,128.77 AUD Unit price per Out of stock! Backorder Now
259.91 Kg	2.00	390.00 mm	36.00 / 23.00 mm	8.80 / 12.00 mm	13.00 / 27.00 mm
P: 4.50 mm Rail Bolt Distance (R): 350.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF18RS Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 390 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $1,297.95 AUD Regular price Sale price $1,297.95 AUD Unit price per Each
259.91 Kg	2.00	390.00 mm	36.00 / 23.00 mm
Rail Dimensions (J/K): 8.80 / 12.00 mm Carriage Dimensions (A/B): 13.00 / 27.00 mm P: 4.50 mm Rail Bolt Distance (R): 350.00 mm Rail Bolt Distance (Q): 25.00 mm Carriage Bolt Distance (C): 27.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF18RS Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 390 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $1,297.95 AUD Regular price Sale price $1,297.95 AUD Unit price per Each View the product page first if you are unsure.
SKF18RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 390 mm SKF18RS --- Rail Systems Miniature Profile Linear - 259.91 Kg - 2 - 390 mm Regular price $1,297.95 AUD Regular price Sale price $1,297.95 AUD Unit price per Out of stock! Backorder Now
336.57 Kg	1.00	150.00 mm	45.50 / 32.50 mm	8.80 / 24.00 mm	14.00 / 40.00 mm
P: 4.50 mm Rail Bolt Distance (R): 120.00 mm Rail Bolt Distance (Q): 45.00 mm Carriage Bolt Distance (C): 40.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF21RS Rail Systems Miniature Profile Linear - 336.57 Kg - 1 - 150 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $677.68 AUD Regular price Sale price $677.68 AUD Unit price per Each
336.57 Kg	1.00	150.00 mm	45.50 / 32.50 mm
Rail Dimensions (J/K): 8.80 / 24.00 mm Carriage Dimensions (A/B): 14.00 / 40.00 mm P: 4.50 mm Rail Bolt Distance (R): 120.00 mm Rail Bolt Distance (Q): 45.00 mm Carriage Bolt Distance (C): 40.00 mm Carriage Bolt Distance (E): 15.00 mm More Information: For more information please contact us
Part Number: SKF21RS Rail Systems Miniature Profile Linear - 336.57 Kg - 1 - 150 mm Out of Stock \| Backorder Now \| Orders can be expected around Wed, May 07, 2025 Regular price $677.68 AUD Regular price Sale price $677.68 AUD Unit price per Each View the product page first if you are unsure.
SKF21RS --- Rail Systems Miniature Profile Linear - 336.57 Kg - 1 - 150 mm SKF21RS --- Rail Systems Miniature Profile Linear - 336.57 Kg - 1 - 150 mm Regular price $677.68 AUD Regular price Sale price $677.68 AUD Unit price per Out of stock! Backorder Now
