Bearings - Single Row Ball - Unflanged - Precision - 316 Stainless - Shields

28 Products in this selection
  • Marine, food and medical grade Stainless Steel - Non Hardenable. 316 stainless steel shields.
  • Tolerances differ from standard bearing types. Due to the tolerance range it is recommended that each actual bearing is measured to calculate fits.
  • Stainless steel 316 cage, grade 200 type 316 stainless balls, 316 stainless races, 316 stainless steel shields.
  • Rings machined from solid rod stock producing true running concentric bearings. Low load, low speed applications requiring maximum corrosion resistance.
  • Usual supply is unlubricated so that they can be used immediately in applications exposed to water, or lubricated by the user with their preferred grease.
  • Special orders can be run with a selected lubricant. Note that some bearings may already be listed with grease.
Additional resources:
Tolerances
Standard Bearings PDF Catalogue
Shafting
A more concise listing may be found on the Smallparts store at Bearings - Single Row Ball - Unflanged - Precision - 316 Stainless - Shields. Smallparts promote the most popular MBA products.
ID (d) OD (D) Width (B) Inner Ring Width (Bn) Flange Diameter (DF) Flange Width (BF) Indicative
ID (d)
25.000
mm
+ 0.102 / - 0.000
(0.984 in.)
OD (D)
47.000
mm
+ 0.000 / - 0.127
(1.85 in.)
Width (B)
12.000
mm
+ 0.127 / - 0.000
(0.472 in.)
Single Row Ball Bearings - 25x47x12 mm - Stainless Steel 316 Similar to A4, 18-10
Material: Stainless Steel 316 (Similar to A4, 18-10)    Precision Grade: Semi-Precision    Closure Type: ZZ    Bearing Type: Radial    Lubricant: Unlubricated
Part Number: S316-6005-ZZ (10 Pcs) Single Row Ball Bearings - 25x47x12 mm - Stainless Steel 316 Similar to A4, 18-10
Out of Stock | Backorder Now | Orders can be expected around Sat, Jun 07, 2025
$145.14 AUD
$145.14 AUD
Per 10
ID (d) OD (D) Width (B) Inner Ring Width (Bn) Indicative
ID (d)
25.000
mm
+ 0.102 / - 0.000
(0.984 in.)
OD (D)
47.000
mm
+ 0.000 / - 0.127
(1.85 in.)
Width (B)
12.000
mm
+ 0.127 / - 0.000
(0.472 in.)
Single Row Ball Bearings - 25x47x12 mm - Stainless Steel 316 Similar to A4, 18-10
Material: Stainless Steel 316 (Similar to A4, 18-10)    Precision Grade: Semi-Precision    Closure Type: ZZ    Bearing Type: Radial    Lubricant: Unlubricated
Part Number: S316-6005-ZZ (10 Pcs) Single Row Ball Bearings - 25x47x12 mm - Stainless Steel 316 Similar to A4, 18-10
Out of Stock | Backorder Now | Orders can be expected around Sat, Jun 07, 2025
$145.14 AUD
$145.14 AUD
Per 10
View the product page first if you are unsure.
ID (d)
25.000
mm
+ 0.102 / - 0.000
(0.984 in.)
OD (D)
52.000
mm
+ 0.000 / - 0.152
(2.047 in.)
Width (B)
15.000
mm
+ 0.127 / - 0.000
(0.591 in.)
Single Row Ball Bearings - 25x52x15 mm - Stainless Steel 316 Similar to A4, 18-10
Material: Stainless Steel 316 (Similar to A4, 18-10)    Precision Grade: Semi-Precision    Closure Type: ZZ    Bearing Type: Radial    Lubricant: Unlubricated
Part Number: S316-6205-ZZ (50 Pcs) Single Row Ball Bearings - 25x52x15 mm - Stainless Steel 316 Similar to A4, 18-10
Out of Stock | Backorder Now | Orders can be expected around Sat, Jun 07, 2025
$1,506.86 AUD
$1,506.86 AUD
Per 50
ID (d)
25.000
mm
+ 0.102 / - 0.000
(0.984 in.)
OD (D)
52.000
mm
+ 0.000 / - 0.152
(2.047 in.)
Width (B)
15.000
mm
+ 0.127 / - 0.000
(0.591 in.)
Single Row Ball Bearings - 25x52x15 mm - Stainless Steel 316 Similar to A4, 18-10
Material: Stainless Steel 316 (Similar to A4, 18-10)    Precision Grade: Semi-Precision    Closure Type: ZZ    Bearing Type: Radial    Lubricant: Unlubricated
Part Number: S316-6205-ZZ (50 Pcs) Single Row Ball Bearings - 25x52x15 mm - Stainless Steel 316 Similar to A4, 18-10
Out of Stock | Backorder Now | Orders can be expected around Sat, Jun 07, 2025
$1,506.86 AUD
$1,506.86 AUD
Per 50
View the product page first if you are unsure.
ID (d)
30.000
mm
+ 0.102 / - 0.000
(1.181 in.)
OD (D)
55.000
mm
+ 0.000 / - 0.152
(2.165 in.)
Width (B)
13.000
mm
+ 0.127 / - 0.000
(0.512 in.)
Single Row Ball Bearings - 30x55x13 mm - Stainless Steel 316 Similar to A4, 18-10
Material: Stainless Steel 316 (Similar to A4, 18-10)    Precision Grade: Semi-Precision    Closure Type: ZZ    Bearing Type: Radial    Lubricant: Unlubricated
Part Number: S316-6006-ZZ (50 Pcs) Single Row Ball Bearings - 30x55x13 mm - Stainless Steel 316 Similar to A4, 18-10
Out of Stock | Backorder Now | Orders can be expected around Sat, Jun 07, 2025
$2,145.23 AUD
$2,145.23 AUD
Per 50
ID (d)
30.000
mm
+ 0.102 / - 0.000
(1.181 in.)
OD (D)
55.000
mm
+ 0.000 / - 0.152
(2.165 in.)
Width (B)
13.000
mm
+ 0.127 / - 0.000
(0.512 in.)
Single Row Ball Bearings - 30x55x13 mm - Stainless Steel 316 Similar to A4, 18-10
Material: Stainless Steel 316 (Similar to A4, 18-10)    Precision Grade: Semi-Precision    Closure Type: ZZ    Bearing Type: Radial    Lubricant: Unlubricated
Part Number: S316-6006-ZZ (50 Pcs) Single Row Ball Bearings - 30x55x13 mm - Stainless Steel 316 Similar to A4, 18-10
Out of Stock | Backorder Now | Orders can be expected around Sat, Jun 07, 2025
$2,145.23 AUD
$2,145.23 AUD
Per 50
View the product page first if you are unsure.
ID (d)
30.000
mm
+ 0.102 / - 0.000
(1.181 in.)
OD (D)
62.000
mm
+ 0.000 / - 0.152
(2.441 in.)
Width (B)
16.000
mm
+ 0.127 / - 0.000
(0.63 in.)
Single Row Ball Bearings - 30x62x16 mm - Stainless Steel 316 Similar to A4, 18-10
Material: Stainless Steel 316 (Similar to A4, 18-10)    Precision Grade: Semi-Precision    Closure Type: ZZ    Bearing Type: Radial    Lubricant: Unlubricated
Part Number: S316-6206-ZZ (50 Pcs) Single Row Ball Bearings - 30x62x16 mm - Stainless Steel 316 Similar to A4, 18-10
Out of Stock | Backorder Now | Orders can be expected around Sat, Jun 07, 2025
$1,792.77 AUD
$1,792.77 AUD
Per 50
ID (d)
30.000
mm
+ 0.102 / - 0.000
(1.181 in.)
OD (D)
62.000
mm
+ 0.000 / - 0.152
(2.441 in.)
Width (B)
16.000
mm
+ 0.127 / - 0.000
(0.63 in.)
Single Row Ball Bearings - 30x62x16 mm - Stainless Steel 316 Similar to A4, 18-10
Material: Stainless Steel 316 (Similar to A4, 18-10)    Precision Grade: Semi-Precision    Closure Type: ZZ    Bearing Type: Radial    Lubricant: Unlubricated
Part Number: S316-6206-ZZ (50 Pcs) Single Row Ball Bearings - 30x62x16 mm - Stainless Steel 316 Similar to A4, 18-10
Out of Stock | Backorder Now | Orders can be expected around Sat, Jun 07, 2025
$1,792.77 AUD
$1,792.77 AUD
Per 50
View the product page first if you are unsure.
