Balls - Metallic - Titanium Alloy - Ti-Gr23 Ti-6Al4V-ELI - Standard

Balls -> Metallic -> Titanium Alloy -> Ti-Gr23 Ti-6Al4V-ELI -> Standard

There are 6 products in the sub-categories of Balls - Metallic - Titanium Alloy - Ti-Gr23 Ti-6Al4V-ELI - Standard. Browse the Balls - Metallic - Titanium Alloy - Ti-Gr23 Ti-6Al4V-ELI - Standard products table.

Category Details

A selection of Standard Ti-Gr23 Ti-6Al4V-ELI Titanium Alloy Metallic Balls. Implant Grade can be used for Jewellery and Body Piercing. Grade 23 6Al-4V is a high strength titanium alloy. Tensile Strength 84.5kgf / mm2. Yield Strength 77.5kgf / mm2. Elongation 10 Percent.

  • Grades shown are AFBMA and ISO3290-1 which relates primarily to the ovality of the ball rather than the diametrical tolerance
  • General balls offered for sale may be from different ball lots, so the diametrical tolerance shown, indicates a variance that might be encountered if balls of different gauges are mixed, unless a ball gauge is specified for the part.
  • For diametrically critical applications, a special quote can be obtained for balls of a specified ball gauge.
  • Plain
  • Composition Percentage: Al 5.5-6.5, V 3.5-4.5, N 0.03, C 0.08, H 0.013, Fe 0.25, O 0.13, Ti Balance
  • Grade 23 6Al-4V is a high strength titanium alloy. Tensile Strength 84.5kgf / mm2. Yield Strength 77.5kgf / mm2. Elongation 10 Percent.

Miniature Bearings Australia - MBA Minibearings

Additional resources:


A more concise listing may be found in the Balls - Metallic - Titanium Alloy - Ti-Gr23 Ti-6Al4V-ELI - Standard category on the Small Parts & Bearings online store.
Diameter (D) Material Precision Hardness Properties Colour Indicative
Diameter (D)
3.000
mm
+/- 0.01270
(Equiv. 0.118 in.)
Material
Ti-Gr23/Ti-6AL4V-ELI

Precision
ISO 3290 Grade 100

Hardness
35 Rockwell C
Properties
Implant Grade Titanium
Colour
Silver
Metallic Balls - 3 mm Ti-Gr23/Ti-6AL4V-ELI - Grade 100
Material: Ti-Gr23/Ti-6AL4V-ELI    Ovality: +/-0.00250
Part Number: BL-00300-T23-G100 (10 Pcs)
Metallic Balls - 3 mm Ti-Gr23/Ti-6AL4V-ELI - ISO 3290 Grade 100 Titanium Alloy Ball
61 units (610 pcs) Available Now | Further orders can be expected around Sun, Oct 19, 2025
$3.23 AUD
$3.23 AUD
Per 10
Quantity Required

61 units (610 pcs) Available Now. Backorder if more than 61.
Diameter (D) Material Precision Hardness Indicative
Diameter (D)
3.000
mm
+/- 0.01270
(Equiv. 0.118 in.)
Material
Ti-Gr23/Ti-6AL4V-ELI

Precision
ISO 3290 Grade 100

Hardness
35 Rockwell C
Metallic Balls - 3 mm Ti-Gr23/Ti-6AL4V-ELI - Grade 100
Material: Ti-Gr23/Ti-6AL4V-ELI    Properties: Implant Grade Titanium    Colour: Silver    Ovality: +/-0.00250
Part Number: BL-00300-T23-G100 (10 Pcs)
Metallic Balls - 3 mm Ti-Gr23/Ti-6AL4V-ELI - ISO 3290 Grade 100 Titanium Alloy Ball
61 units (610 pcs) Available Now | Further orders can be expected around Sun, Oct 19, 2025
$3.23 AUD
$3.23 AUD
Per 10
Quantity Required

61 units (610 pcs) Available Now. Backorder if more than 61.
Diameter (D)
4.000
mm
+/- 0.01270
(Equiv. 0.157 in.)
Material
Ti-Gr23/Ti-6AL4V-ELI

Precision
ISO 3290 Grade 100

Hardness
35 Rockwell C
Properties
Implant Grade Titanium
Colour
Silver
Metallic Balls - 4 mm Ti-Gr23/Ti-6AL4V-ELI - Grade 100
Material: Ti-Gr23/Ti-6AL4V-ELI    Ovality: +/-0.00250
Part Number: BL-00400-T23-G100 (10 Pcs)
Metallic Balls - 4 mm Ti-Gr23/Ti-6AL4V-ELI - ISO 3290 Grade 100 Titanium Alloy Ball
48 units (480 pcs) Available Now | Further orders can be expected around Sun, Oct 19, 2025
$3.23 AUD
$3.23 AUD
Per 10
Quantity Required

48 units (480 pcs) Available Now. Backorder if more than 48.
Diameter (D)
4.000
mm
+/- 0.01270
(Equiv. 0.157 in.)
Material
Ti-Gr23/Ti-6AL4V-ELI

Precision
ISO 3290 Grade 100

Hardness
35 Rockwell C
Metallic Balls - 4 mm Ti-Gr23/Ti-6AL4V-ELI - Grade 100
Material: Ti-Gr23/Ti-6AL4V-ELI    Properties: Implant Grade Titanium    Colour: Silver    Ovality: +/-0.00250
Part Number: BL-00400-T23-G100 (10 Pcs)
Metallic Balls - 4 mm Ti-Gr23/Ti-6AL4V-ELI - ISO 3290 Grade 100 Titanium Alloy Ball
48 units (480 pcs) Available Now | Further orders can be expected around Sun, Oct 19, 2025
$3.23 AUD
$3.23 AUD
Per 10
Quantity Required

48 units (480 pcs) Available Now. Backorder if more than 48.
Diameter (D)
5.000
mm
+/- 0.01270
(Equiv. 0.197 in.)
Material
Ti-Gr23/Ti-6AL4V-ELI

Precision
ISO 3290 Grade 100

Hardness
35 Rockwell C
Properties
Implant Grade Titanium
Colour
Silver
Metallic Balls - 5 mm Ti-Gr23/Ti-6AL4V-ELI - Grade 100
Material: Ti-Gr23/Ti-6AL4V-ELI    Ovality: +/-0.00250
Part Number: BL-00500-T23-G100 (5 Pcs)
Metallic Balls - 5 mm Ti-Gr23/Ti-6AL4V-ELI - ISO 3290 Grade 100 Titanium Alloy Ball
28 units (140 pcs) Available Now | Further orders can be expected around Sun, Oct 19, 2025
$3.41 AUD
$3.41 AUD
Per 5
Quantity Required

28 units (140 pcs) Available Now. Backorder if more than 28.
Diameter (D)
5.000
mm
+/- 0.01270
(Equiv. 0.197 in.)
Material
Ti-Gr23/Ti-6AL4V-ELI

Precision
ISO 3290 Grade 100

Hardness
35 Rockwell C
Metallic Balls - 5 mm Ti-Gr23/Ti-6AL4V-ELI - Grade 100
Material: Ti-Gr23/Ti-6AL4V-ELI    Properties: Implant Grade Titanium    Colour: Silver    Ovality: +/-0.00250
Part Number: BL-00500-T23-G100 (5 Pcs)
Metallic Balls - 5 mm Ti-Gr23/Ti-6AL4V-ELI - ISO 3290 Grade 100 Titanium Alloy Ball
28 units (140 pcs) Available Now | Further orders can be expected around Sun, Oct 19, 2025
$3.41 AUD
$3.41 AUD
Per 5
Quantity Required

28 units (140 pcs) Available Now. Backorder if more than 28.
Diameter (D)
6.000
mm
+/- 0.01270
(Equiv. 0.236 in.)
Material
Ti-Gr23/Ti-6AL4V-ELI

Precision
ISO 3290 Grade 100

Hardness
35 Rockwell C
Properties
Implant Grade Titanium
Colour
Silver
Metallic Balls - 6 mm Ti-Gr23/Ti-6AL4V-ELI - Grade 100
Material: Ti-Gr23/Ti-6AL4V-ELI    Ovality: +/-0.00250
Part Number: BL-00600-T23-G100 (10 Pcs)
Metallic Balls - 6 mm Ti-Gr23/Ti-6AL4V-ELI - ISO 3290 Grade 100 Titanium Alloy Ball
39 units (390 pcs) Available Now | Further orders can be expected around Sun, Oct 19, 2025
$9.68 AUD
$9.68 AUD
Per 10
Quantity Required

39 units (390 pcs) Available Now. Backorder if more than 39.
Diameter (D)
6.000
mm
+/- 0.01270
(Equiv. 0.236 in.)
Material
Ti-Gr23/Ti-6AL4V-ELI

Precision
ISO 3290 Grade 100

Hardness
35 Rockwell C
Metallic Balls - 6 mm Ti-Gr23/Ti-6AL4V-ELI - Grade 100
Material: Ti-Gr23/Ti-6AL4V-ELI    Properties: Implant Grade Titanium    Colour: Silver    Ovality: +/-0.00250
Part Number: BL-00600-T23-G100 (10 Pcs)
Metallic Balls - 6 mm Ti-Gr23/Ti-6AL4V-ELI - ISO 3290 Grade 100 Titanium Alloy Ball
39 units (390 pcs) Available Now | Further orders can be expected around Sun, Oct 19, 2025
$9.68 AUD
$9.68 AUD
Per 10
Quantity Required

39 units (390 pcs) Available Now. Backorder if more than 39.
Diameter (D)
8.000
mm
+/- 0.01270
(Equiv. 0.315 in.)
Material
Ti-Gr23/Ti-6AL4V-ELI

Precision
ISO 3290 Grade 100

Hardness
35 Rockwell C
Properties
Implant Grade Titanium
Colour
Silver
Metallic Balls - 8 mm Ti-Gr23/Ti-6AL4V-ELI - Grade 100
Material: Ti-Gr23/Ti-6AL4V-ELI    Ovality: +/-0.00250
Part Number: BL-00800-T23-G100 (10 Pcs)
Metallic Balls - 8 mm Ti-Gr23/Ti-6AL4V-ELI - ISO 3290 Grade 100 Titanium Alloy Ball
3 units (30 pcs) Available Now | Further orders can be expected around Sun, Oct 19, 2025
$17.50 AUD
$17.50 AUD
Per 10
Quantity Required

3 units (30 pcs) Available Now. Backorder if more than 3.
Diameter (D)
8.000
mm
+/- 0.01270
(Equiv. 0.315 in.)
Material
Ti-Gr23/Ti-6AL4V-ELI

Precision
ISO 3290 Grade 100

Hardness
35 Rockwell C
Metallic Balls - 8 mm Ti-Gr23/Ti-6AL4V-ELI - Grade 100
Material: Ti-Gr23/Ti-6AL4V-ELI    Properties: Implant Grade Titanium    Colour: Silver    Ovality: +/-0.00250
Part Number: BL-00800-T23-G100 (10 Pcs)
Metallic Balls - 8 mm Ti-Gr23/Ti-6AL4V-ELI - ISO 3290 Grade 100 Titanium Alloy Ball
3 units (30 pcs) Available Now | Further orders can be expected around Sun, Oct 19, 2025
$17.50 AUD
$17.50 AUD
Per 10
Quantity Required

3 units (30 pcs) Available Now. Backorder if more than 3.
Diameter (D)
10.000
mm
+/- 0.01270
(Equiv. 0.394 in.)
Material
Ti-Gr23/Ti-6AL4V-ELI

Precision
ISO 3290 Grade 100

Hardness
35 Rockwell C
Properties
Implant Grade Titanium
Colour
Silver
Metallic Balls - 10 mm Ti-Gr23/Ti-6AL4V-ELI - Grade 100
Material: Ti-Gr23/Ti-6AL4V-ELI    Ovality: +/-0.00250
Part Number: BL-01000-T23-G100 (1000 Pcs)
Metallic Balls - 10 mm Ti-Gr23/Ti-6AL4V-ELI - ISO 3290 Grade 100 Titanium Alloy Ball
Out of Stock | Backorder Now | Orders can be expected around Sun, Oct 19, 2025
$4,024.41 AUD
$4,829.29 AUD $4,024.41 AUD
Per 1000
Quantity Required

Backorder: Out of Stock.
Diameter (D)
10.000
mm
+/- 0.01270
(Equiv. 0.394 in.)
Material
Ti-Gr23/Ti-6AL4V-ELI

Precision
ISO 3290 Grade 100

Hardness
35 Rockwell C
Metallic Balls - 10 mm Ti-Gr23/Ti-6AL4V-ELI - Grade 100
Material: Ti-Gr23/Ti-6AL4V-ELI    Properties: Implant Grade Titanium    Colour: Silver    Ovality: +/-0.00250
Part Number: BL-01000-T23-G100 (1000 Pcs)
Metallic Balls - 10 mm Ti-Gr23/Ti-6AL4V-ELI - ISO 3290 Grade 100 Titanium Alloy Ball
Out of Stock | Backorder Now | Orders can be expected around Sun, Oct 19, 2025
$4,024.41 AUD
$4,829.29 AUD $4,024.41 AUD
Per 1000
Quantity Required

Backorder: Out of Stock.
