IDRS150250-50-3S - Datasheet

MBA

Product Data

• Roller Outside Diameter : 15.000 mm
• Roller Width 25.000 mm
• Shaft Diameter 5.000 mm
• Right Shaft Projection 12.000 mm
• Bearing Type Sintered Bronze Bearing
• Overall Length 50.000
• Housing Material 303 Stainless Steel
• Bearing Material Sintered Bronze
• Material Stainless Steel 303/304 (Similar to A2, 18-8) HRB80

Product Compliance and Data

• RoHs Statement
• REACH Statement
• CoC
