GR-M2-20-0500-20-C - Datasheet
MBA
Category Information
Gears - Rack - Metric - Module 2 - SteelSteel Module 2 Metric Rack Gears. 20 Degree Pressure Angle. Carbon steel
- Be sure to match the pitch type and tooth angle when selecting rack and spur gears.
- An expanded range may be available on special order. Please enquire.
- Lengths longer than 1mtr can only be shipped internationally using Express not post. Please do not select post at checkout for long lengths.
Product Data
- Length (L) : 500 mm
- Face Width (fw) 20.000 mm
- Height (h) 20.000 mm
- Pitch Type Module 2
- Pitch Height (ph) 18.000 mm
- Pressure Angle 20 °
- Precision ISO 8 (AGMA Q9)
- Mounting Holes None
- Shape Square
- Material Carbon Steel
