Miniature Bearings Australia
BP0300-0350-0300-BSLT - Datasheet
MBA
Category Information
Bushes - Unflanged - Bronze - SinteredSintered Bronze Unflanged Bushes. Oil impregnated sintered bronze bushes.
- An expanded range may be available on special order. Please enquire.
- Precision items show an allowable Load Speed Rating in Newtons times RPM.
Product Data
- Nominal Inside Diameter (d)
:
30.000
mm
+ 0.005 / + 0.030
(Equiv. 1.181 in.) - Nominal Outside Diameter (D)
35.000
mm
+ 0.040 / + 0.070
(Equiv. 1.378 in.) - Length (s)
30.000
mm
+/- 0.127
(Equiv. 1.181 in.)
Product Compliance and Data
Additional Resources
- DU Bush Material Information
- General Bushes Catalogue
- Sintered Bronze Products Catalogue
- Solid Bronze Bushes catalogue
Cross References
- Oilite AM-3035-30
- Oilube AM-3035-30
- BP030003500300BSTH
- AM303530
- QM3730
- QM37-30
