Miniature Bearings Australia
ORB-24089-353-S70-272-R - Datasheet
MBA
Category Information
O-Rings - Silicone Rubber BulkSilicone Rubber Bulk O-Rings. High thermal resistance and cold flexibility. Some dental applications are included in the listings. Commonly used in food applications.
- Silicone O-Rings have high thermal resistance and cold flexibility.
- Some dental applications are included in the listings. Commonly used in food applications.
- Mulitple packs may be supplied together in a singular package.
- Temperature Range: -70 Deg C to +200 Deg C.
- Good dialectric properties and resistance to ozone and oxygen attack.
- Retains flexibility at high and low temperatures.
- Poor strength and tear resistance. Poor resistance to oils, fuels, concentrated acids and alkalis, water and steam.
- Bulk stock orders are the most economical way to purchase, but smaller packs are available for some sizes.
Product Data
- Inside Diameter (ID)
:
240.89
mm
(Equiv. 9.484 in.) - Section (t)
3.53
mm
(Equiv. 0.139 in.) - Colour Red
- Hardness Duro 70
- Material Silicone Rubber
Product Compliance and Data
Additional Resources
Cross References
- OR24089353S70272R
- OR-24089-353-S70-272-R
